DISASSEMBLY

• Disassemble in order of the arrow in the following figure.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT
(Ref. No. of EXPLODED VIEW : C1)
PCB HP
(Ref. No. of EXPLODED VIEW : C2)
PCB FRONT HDMI FFC CABLE
(Ref. No. of EXPLODED VIEW : C3)
PCB FRONT HDMI
(Ref. No. of EXPLODED VIEW : C4)
PCB USB
(Ref. No. of EXPLODED VIEW : C5)
CABINET TOP
HEAT SINK ASSY
Refer to "DISASSEMBLY
2. HEAT SINK ASSY"
and "EXPLODED VIEW"
PCB GUIDE L
(Ref. No. of EXPLODED VIEW : C7)
PCB GUIDE R
(Ref. No. of EXPLODED VIEW : C8)
7CH AMP PCB ASSY
(Ref. No. of EXPLODED VIEW : C9)
PCB GUIDE_VIDEO
(Ref. No. of EXPLODED VIEW : C10)
11
DIGITAL UNIT ASSY
Refer to "DISASSEMBLY
3. DIGITAL UNIT ASSY"
and "EXPLODED VIEW"
PCB SMPS
(Ref. No. of EXPLODED VIEW : C6)
PCB FRONT_CNT
(Ref. No. of EXPLODED VIEW : C12)
PCB FUSE
(Ref. No. of EXPLODED VIEW : C13)
PCB SPK_PREOUT
(Ref. No. of EXPLODED VIEW : C14)
PCB SIDE_CNT
(Ref. No. of EXPLODED VIEW : C15)
PCB INPUT
(Ref. No. of EXPLODED VIEW : C16)
PCB F_WIDE
(Ref. No. of EXPLODED VIEW : C17)
PCB VIDEO
(Ref. No. of EXPLODED VIEW : C18)
PCB GUIDE
(Ref. No. of EXPLODED VIEW : C19)
PCB DIGITAL
(Ref. No. of EXPLODED VIEW : C20)
POWER TRANS
Refer to "DISASSEMBLY
4. POWER TRANS"
and "EXPLODED VIEW"
PCB POSISTOR
(Ref. No. of EXPLODED VIEW : C10)
TRANS , POWER
(Ref. No. of EXPLODED VIEW : C11)
