OWNER'S MANUAL
CYCLONIK SERIES
MAN.CYC.AN
PRINTED IN CANADA (02-21)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CYCLONIK Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Drainvac CYCLONIK Series

  • Page 1 Cleaning Systems OWNER’S MANUAL CYCLONIK SERIES MAN.CYC.AN PRINTED IN CANADA (02-21)
  • Page 2 • The Cyclonik series is designed to pick up small quantities of liquids only, up to 16 L Drainvac disclaims any responsibility should you infringe upon these guidelines. (3.5 imp. gal.). However, models DV1R800 and DF1R630 cannot pick up any liquid.
  • Page 3: Table Of Contents

    MODEL TYPE We wish to thank you for your trust and congratulate you for having chosen a Drainvac ........... . 6-7 product.
  • Page 4: Model Type

    MODEL TYPE MODEL TYPE You have purchased one of the following models. Identify the one related to it. The model number is marked on the label stuck on the left side of the head. COMMERCIAL SERIES NORTH AMERICA (108V - 120V) MODELS DECIBELS AMPS...
  • Page 5: Unit Description

    UNIT DESCRIPTION UNIT DESCRIPTION Audioprotek muffler Exhaust muffler Audioprotek muffler 24V plug 24V plug Exhaust muffler Audioprotek muffler Power cord Power cord Canister Canister DV1R12-CT / DV1R12-CTTM* DV1R15-CT / DV1R15-CTTM* / DF1R15 *The DV1R12-CTTM model has an hour meter. *The DV1R15-CTTM model has an hour meter.
  • Page 6 UNIT DESCRIPTION UNIT DESCRIPTION Audioprotek muffler Exhaust muffler 24V plug 24V plug Exhaust muffler Power cord Power cord Foam filter Canister Canister DV1R800 / DF1R630 DF1R11...
  • Page 7 UNIT DESCRIPTION UNIT DESCRIPTION Exhaust muffler Exhaust muffler Audioprotek muffler Audioprotek muffler 24V plug 24V plug Audioprotek muffler Audioprotek muffler Power cord* Power cord* Canister Canister DV1R19-27CT / DF1R19-CT DV1R20-27CT / DF1R20-CT...
  • Page 8: Installation

    INSTALLATION INSTALLATION - FIRST THINGS FIRST - - FIRST THINGS FIRST - REQUIRED TOOLS WHERE TO INSTALL THE UNIT We recommend installing the system on the lowest level of the building to avoid having to work against gravity. Dust and solids will fall easier than being pulled upwards, this is why the basement is generally the most ideal location.
  • Page 9: Mounting The Unit To The Wall

    INSTALLATION INSTALLATION 1) MOUNTING THE UNIT ON THE WALL • Lift the unit and slide its support onto the wall bracket. • Undo the fastener securing the wall bracket and base at the back of the unit with cutting pliers. Cut the fastener •...
  • Page 10: Audioprotek Muffler / Air Outlet

    INSTALLATION INSTALLATION 3) AUDIOPROTEK MUFFLER MUFFLER All Cyclonik systems are supplied with Audioproteks, • Connect the air outlet to the unit, securing it with a clamp and install the muffler except for models DV1R800 and DF1R630. with a second collar (do not glue). •...
  • Page 11 PIPING INSTALLATION PIPING INSTALLATION The following pages illustrate piping diagrams, typical installations and the parts that we recommend for an optimum performance of your central vacuum system. GENERAL INFORMATION Short elbow • You must plan to install an air outlet leading outside for these units but make sure that the evacuated air does not lead under a carport.
  • Page 12: Piping Installation

    PIPING INSTALLATION WEEE GUIDELINES DIAGRAM OF A RESIDENTIAL INSTALLATION DIFFERENT INSTALLATION POSSIBILITIES Dry pipeline Always have a slight Wet pipeline inclination of the piping towards the unit. Exhaust pipeline On the top floor (at the end of a pipeline) On an intermediary floor On the first floor (connected above a pipeline under the floor)
  • Page 13: Examples Of Proper And Improper Installations

    PIPING INSTALLATION PIPING INSTALLATION DIAGRAM OF A COMMERCIAL INSTALLATION EXAMPLES OF PROPER Installation example in series AND IMPROPER INSTALLATIONS Through the ceiling Thick wall Under the floor Thin wall For wall plates only Always have a slight inclination of the piping towards the unit. Smooth joint without Joint with inside stoppers inside stoppers...
  • Page 14 PIPING INSTALLATION PIPING INSTALLATION EXAMPLES OF PROPER EXAMPLES OF PROPER AND IMPROPER INSTALLATIONS AND IMPROPER INSTALLATIONS...
  • Page 15: Electrical Power Supply

    ELECTRICAL POWER SUPPLY ELECTRICAL POWER SUPPLY DIAGRAMS OF AN APPROPRIATE CONNECTION An electrical cord is equipped to all central vacuum systems. An adequate electrical power outlet must be installed near the unit. We strongly recommend installing an If you experience voltage surge problems on your electrical circuit in spite of adequate electrical circuit which will only be used for the unit.
  • Page 16: Grounding Instructions

    ELECTRICAL POWER SUPPLY MAINTENANCE PROCEDURES GROUNDING INSTRUCTIONS CARTRIDGE FILTER These units must be grounded. If it should malfunction or breakdown, grounding You must clean the cartridge filter every 6 months to prevent your unit from losing any provides a path of least resistance for electric current to reduce the risk of electric suction power and extend its lifespan.
  • Page 17: Technical Problems / Support

    TECHNICAL PROBLEMS THE UNIT WON’T START UP... SOLUTION : 1) Check if the LED is lit. 2) Check the circuit breaker in your electrical panel. 3) Check the unit’s circuit fuse/breaker. 4) Check the 24-volt circuit, as follows : Establish an electrical contact between the two 24V circuit terminals of the unit with a metal object such as a screwdriver or a coin.
  • Page 19 Central Vacuums...
