4. Usage advice and specification
Minimum working pressure*:
NOTE:
The minimum working pressure refers to the pressure required to operate the valve. Higher pressure
may be required for an effective flush, depending on the bowl and sparge outlet design.
Maximum working pressure:
NOTE:
When using the Direct Flush valve from a mains water supply, the pressure may be higher than is
suitable for the design of the sparge or bowl which may cause splashing to occur. In such cases a
pressure reducing valve on the supply may be required to reduce the pressure as necessary.
Back siphonage protection:

Factory settings

Range:
Flush time:
Flush delay:
Power requirements:
Normal battery life:
Cleaning:
Lens care:

Electronic specification

Control classification – DFD:
Control classification – DFA:
Maximum load:
Rated temperature range:
Action classification:
Pollution classification:
Ingress protection:
10 | www.cistermiser.co.uk
0.5 bar.
*Working or dynamic pressure is measured when water is flowing.
6 bar
Class 5, type DC
Circa 50cm
7 seconds
2 seconds
Either 6V from 4 x alkaline AA (LR6) batteries or 6V DC
regulated from mains adaptor (1A fused spur required).
2 years under typical usage conditions. A single red flashing of the
LED indicates that the batteries are low and need to be replaced.
Clean with soap and water only.
Infrared lens can be polished with a soft cloth.
Independent
Independent
2W 0.33A
0-40°C.
Type 1.Y
Degree 1
IP65.
