Table of Contents Introduction............................3 Safety instructions ..........................3 Specified application..........................3 Installation and connection........................4 Mounting information......................4 Connection diagram GFM001 ....................4 First start-up and commissioning ......................4 Control functions..........................5 Manual operating functions ....................5 Automatic operating functions....................5 Extensions and individual settings ....................6 7.1. Learning of radio commands ....................6 Coding set in the condition as delivered ................6...
1 Introduction By deciding to buy the awning control system GFM001 you have made a good choice. The device you have acquired is a high quality product made by Geiger. The control system has been designed for the exclusive operation via radio commands.
4 Installation and connection 4.1 Mounting information The distance between two GFM001 control systems should come to at least 0.5 meter. 4.2 Connection diagram GFM001 Depending on the installation position of the drive, the sense of rotation must be changed.
6 Control functions 6.1 Manual operating functions Generally, the following applies: The control system is equipped with a fixed motor running time limitation of 140 seconds for the extension of the awning and of a limitation of 155 seconds for its retraction.
7.2 Coding condition as delivered The coding preset by Geiger can be learned from the picture shown left hand (coding condition as delivered). If several control systems are to be installed that shall be operated individually, each radio receiver must get its individual coding.
7.4 Learning of a sensor 1. Power off and on the power supply of the awning control system shortly (overall time available for the execution of the learning procedure as of this moment: 10 minutes). 2. Hold the hand-held transmitter close to the antenna of the GFM… awning control and keep the key "AUF"...
1. Power off and on the mains voltage (overall time available as of this moment for the execution of this procedure: 10 minutes). 2. Hold the hand-held transmitter (e.g. GF0001) close to the antenna of the GFM001. 3. Keep the key "AUF" depressed for approx. 3 sec. until an audible signal resounds (long tone).
EC directive 1999/5/EG and that it is licensed for use in all member states of the EU and in Switzerland without any need of prior registration. To learn more about the Declaration of Conformity pertaining to this device, please visit our website at: www.geiger.de...
Page 10
They will be happy to assist you. Gerhard Geiger GmbH & Co. KG Schleifmühle 6 | D-74321 Bietigheim-Bissingen T +49 (0) 7142 9380 | F +49 (0) 7142 938 230 info@geiger.de | www.geiger.de Gerhard Geiger GmbH & Co. KG | 100W0619 0221...
