Nayax VPOS Touch User Manual page 16

Title
No.
VPOS
1 Touch
Connector
External
Antenna
2 Adapter
(replace
image)
Sim
3
Housing
3. Test the following payment cards:
I. Magnetic Card – In case of an error, check the Magnetic Head connection to the
board – Refer to Image 4.
II. Contact Card & Contactless Card - In case of an error, send it to the Nayax
Laboratory
III. In case the speaker is not functional, check the Speaker Connection to the board –
Refer to Image
Revision 1.6.4
VPOS Touch cable connector (same connector for
Note: To disconnect the connector, press the
latch (indicated with an arrow) before pulling
out the cable.
The External Antenna adapter connects to the
board and to the External Antenna that is
The SIM socket is opened by pulling up and closed
VPOS Touch User Manual
Description
MDB and Pulse cables).
provided by Nayax.
by puling down the socket.
Page 16
