Summary of Contents for Tektronix WFM 601A

  • Page 1 (217) 352-9330 | Click HERE Find the Tektronix WFM 601M at our website:...
  • Page 2 User Manual WFM 601A, WFM 601E & WFM 601M Serial Digital Component Waveform Monitors 071-0103-01 This document supports firmware version 1.00 and above. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3 Copyright Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A. Tektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000 TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
  • Page 4 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.
  • Page 5 Eliminates unexpected service expenses For Information and Ordering For more information or to order Service Assurance, contact your Tektronix representative and provide the information below. Service Assurance may not be available in locations outside the United States of America. Name...
  • Page 6 ............3–44 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 7: Table Of Contents

    DGTL:BASE <HEX | DECIMAL | BINARY> (WFM 601M Only) ..C–24 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 8 ......... . . C–35 GAIN:AUDIO <DBU0 | DBU4 | DBU8 | DBU12> (WFM 601A Only) ..
  • Page 9 ......... . . D–3 Glossary Index WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 10 ......2–1 Figure 2–2: WFM 601A and WFM 601E front panels ... .
  • Page 11 ....D–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 12 ......C–51 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 13 Table of Contents viii WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 14 Terms in this Manual. These terms may appear in this manual: WARNING. Warning statements identify conditions or practices that could result in injury or loss of life. WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 15 Refer to the specifications section for a listing of certifications and compliances Compliances that apply to this product. WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 16 Preface This manual describes the capabilities of the WFM 601A, WFM 601E, and WFM 601M Serial Digital Component Waveform Monitors and their features and specifications. To get started, refer to the first section, Getting Started. This section shows you how to install and configure the waveform monitor for use in your operating environment.
  • Page 17 For product support outside of North America, contact your local Tektronix distributor or sales office. Service Contact your local Tektronix distributor or sales office. Or visit Support our web site for a listing of worldwide service locations. http://www.tek.com For other...
  • Page 18 Getting Started Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 19 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 20 Field, line, and word (WFM 601M only) select with readout and bright up of selected lines on Picture Monitor Out (Y or G Channel) 1–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 21 High-frequency, End-line Terminations: 26 dB to 300 MHz (011–0163–00) Smoke Grey CRT Filter, installed on instrument (378–0258–00) 1–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 22 Optional Accessories The following items can be ordered with the monitor or purchased through a Tektronix field office or distributor. When ordering, include both the name and part number (if available) of the option. WFM 601A, WFM 601E, and WFM 601M Service Manual. (070-9836-XX) Provides module-level troubleshooting information plus information to help identify components, such as schematics, component locaters, and a complete parts list.
  • Page 23 1700F07 utility drawer in the unused side to provide storage and improve appearance and air flow. The drawer opens and closes freely, unless latched for transport. 1–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 24 NOTE. To meet EMI emission specifications, the waveform monitor must be installed in a Tektronix 1700F00, 1700F02, or 1700F05 enclosure. The enclosure front edges must securely contact the conductive front bezel on all four sides.

  • Page 25: Figure 1-1: Dimensions Of The 1700F00 Plain Cabinet

    1700F02 Portable carrying case is an enhanced version of the 1700F00 cabinet, as is the 1700F05 side-by-side rack mount assembly. All cabinets are available from your Tektronix representative. 1–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 26: Figure 1-2: 1700F02 Portable Cabinet

    21 cm (8.25 in) 42.7 cm (16.2 in) 13 cm (5.1 in) Figure 1–2: 1700F02 portable cabinet 1–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 27: Figure 1-3: Rear View Of The Waveform Monitor In A 1700F02 Cabinet

    Cabinet securing screws Figure 1–3: Rear view of the waveform monitor in a 1700F02 cabinet 1–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 28: Figure 1-4: The 1700F05 Rack Cabinet Holds Two Instruments

    Mounting (17.3 in) holes Front panel alignment holes Figure 1–4: The 1700F05 rack cabinet holds two instruments 1–9 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 29: Figure 1-5: 1700F05 Cabinet Showing Utility Drawer And Blank Panel

    1700F06 Figure 1–5: 1700F05 cabinet showing utility drawer and blank panel Repackaging for To ship the waveform monitor to a Tektronix Service Center for service, follow Shipment these instructions: 1. Attach a tag to the waveform monitor showing the name of the owner, the complete address, the phone number, the instrument serial number and a description of the required service.
  • Page 30 Refer to page 1–2 for the power cord options. The typical power draw is 75 W. Refer to Appendix A: Specifications for additional information on power and environmental requirements. 1–11 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 31: Figure 1-6: Monitoring The Video Bit Stream Of A Serial Receiver

    SER B Loop-through input Figure 1–6: Monitoring the video bit stream of a serial receiver 1–12 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 32: Figure 1-7: Monitoring Serial Digital Signals Around A Routing Switcher

    A terminator can be inspected for return loss problems using the WFM 601M or WFM 601E waveform monitor and a serial source with low aberrations, such as the Tektronix TG 2000 mainframe with a DVG1 Generator module. Connect the generator serial output to one side of the waveform monitor loop-through connector and install the terminator on the other side.

  • Page 33: Figure 1-8: Eye Pattern Display Of A Termination With Good Return Loss

    Do not use connectors or terminators with the smaller center pins. They could cause intermittent connections. 1–14 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 34 The following equipment is required to perform this procedure: Digital Component Television Signal Generator (1) Provides 100% Color Bar signal. For example: The Tektronix TG 2000 Signal Generation Platform with a DVG1 module. Function generator (1) (for WFM 601A only)

  • Page 35: Figure 1-10: Initial Equipment Connections

    4. Terminate the other side of the loop-through the SER A input with the 75 terminator. 5. For the WFM 601A only, connect one of the Function Generator audio outputs to pins 8 and 9 of the REMOTE 25-pin connector; connect the other output to pins 10 and 11.
  • Page 36 Check for the Waveform display mode with one channel of the Color Bar signal displayed. Your display should look similar to Figure 1–11. 1–17 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 37: Figure 1-11: Initial Display In The Waveform Display Mode

    Functional Check @ 525/2:1 10 S/DIV Figure 1–11: Initial display in the Waveform display mode 1–18 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 38 Exit the CRT menu by pressing the CRT button. The changes made while the menu was displayed remain in effect. 1–19 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 39: Figure 1-13: Eye Pattern Display Mode

    Figure 1–14. Jitter values are affected by the quality of the signal source and connecting cables. 1–20 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 40: Figure 1-14: Jitter Display Mode

    Press the bezel button labeled VECTOR/LIGHTNING to select the Lightning display. e. Check that the display looks like the Lightning display pictured in Figure 1–16. 1–21 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 41 Figure 1–15: Vector display for a 100% Color Bar signal @ 525/2:1 VECTOR LIGHTNING Figure 1–16: Lightning display for a 100% Color Bar signal 1–22 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 42: Figure 1-17: Arrowhead Gamut Display

    Check that the display looks like the Arrowhead gamut display in Figure 1–17. @ 525/2:1 ARROWHEAD DIAMOND | C | Figure 1–17: Arrowhead gamut display 1–23 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 43: Figure 1-18: Diamond Gamut Display

    VIDEO. c. Check that the display looks like the Video digital waveform display in Figure 1–19. 1–24 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 44: Figure 1-19: Video Digital Waveform

    Press the bezel button again to select the DATA display mode. e. Check that the display looks like the Data digital waveform display in Figure 1–20. 1–25 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 45: Figure 1-20: Data Digital Waveform

    LINE SEL SAMPLE Figure 1–20: Data digital waveform 12. Check the Audio display mode. (WFM 601A only) a. Set the function generator for a sine wave at 1 kHz and 10 Vpk-pk or less amplitude. b. Press the ANALOG AUDIO button. The AUDIO button indicator should light.
  • Page 46 Operating Basics Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 47 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 48: Figure 2-1: Wfm 601M Front Panel

    For detailed informa- tion, refer to section 3, Reference. Figure 2–1: WFM 601M front panel 2–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 49: Figure 2-2: Wfm 601A And Wfm 601E Front Panels

    Functional Overview WFM 601A front panel WFM 601E front panel Figure 2–2: WFM 601A and WFM 601E front panels DISPLAY and VIDEO Six buttons in the DISPLAY or VIDEO DISPLAY area control the type of DISPLAY Buttons display. Most buttons represent two related types of displays. Press a button to select one of its two displays.
  • Page 50 The Lissajous pattern will take one of three general forms: a line, an ellipse, or a circle. 2–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 51 Provides access to configuration and measurement functions that affect the DISPLAY mode. Press a MENU button to display that menu and enable the 2–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 52: Figure 2-3: Elements Of The Waveform Monitor Menu Controls

    Menu selection buttons Menu clear Bezel knobs Figure 2–3: Elements of the waveform monitor menu controls 2–5 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 53: Figure 2-4: Rear Panel Of The Waveform Monitor

    Appendix A: Specifications for additional information on power and environmen- tal requirements. Power connector Figure 2–4: Rear panel of the waveform monitor 2–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 54 RS-232. This 9-pin subminiature D-type connector provides a serial interface for remote control and calibration. REMOTE. This 25-pin subminiature D-type connector provides limited remote control functions. 2–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 55 Functional Overview 2–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 56 Reference Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 57 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 58: Figure 3-1: A Signal From One Channel Only

    Y channel only, as shown in the figure on the right. Figure 3–1: A signal from one channel only 3–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 59: Figure 3-2: X And Y Signal In Phase With Equal Amplitudes

    Figure 3–3: Signals out of phase with equal amplitudes 3–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 60: Figure 3-4: Signals Out Of Phase With Unequal Amplitudes

    See Figure 3–6. Figure 3–6: Signals with a phase error of 90 degrees and equal amplitudes 3–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 61: Figure 3-7: Typical Audio Display Pattern With Small Phase Error

    1. While in the Audio display mode, press the GAIN menu button. 2. Press one of the bezel buttons to select the appropriate calibration level. 3–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 62 The Bowtie display evaluates the relative amplitude and timing between the three video channels. This display requires a special test signal from the monitored source. See Figure 3–8. The Tektronix TG 2000 Waveform Generator can produce a bowtie signal with 20 ns time marks, which aid in signal evaluation.
  • Page 63 Incomplete null Figure 3–10: Bowtie waveform showing gain error in CH 3 3–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 64 5. If the gain is off slightly, adjust the horizontal gain with the H CAL bezel knob. If the H CAL knob is not available, press the GAIN CAL button. 3–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 65 Configure menus. Press the CONFIG button again to remove the Configure menu. 3–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 66 In Pass mode all digital data is sent to the converters. 3–9 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 67 READOUT. Determines whether the jitter measurement is in the units UI (unit intervals) or seconds or if the readout is off. 3–10 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 68 The AFC mode is best in most situations. Use the Direct mode when large, low-frequency jitter is present in your system. 3–11 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 69 Pressing the top CRT bezel button once moves the cursor to READOUT and reduces the intensity again. At this 3–12 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 70 Time Cursors measurements are possible with MAG on, though both cursors may be off screen. The measurements are accurate, even though you cannot see the 3–13 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 71 374 h DECIMAL 3A6 h BINARY LINE SEL SAMPLE Figure 3–13: Example of the Digital List display 3–14 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 72 Field bezel button to alternate between fields in a frame. The Sample knob scrolls to the end of the line then returns to the beginning of the line. 3–15 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 73 Note that Y and Y’ samples are interleaved to create the CH 1 waveform. As you move the data cursor through the CH 1 data, the label 3–16 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 74 274 h F1: 176 SMP 543 ACTIVE LINE SEL SAMPLE Figure 3–16: Digital Waveform display in DATA mode 3–17 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 75 The Sample knob scrolls to the end of the line then returns to the beginning of the line. 3–18 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 76 RP-184 standard. The selected clock bandwidth filter appears in a readout field directly below the horizontal deflection factor. 3–19 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 77 Overlay Eye display. Approximately three eyes are displayed and the horizontal scale is 1 ns/div. 100 mV/DIV 1 nS/DIV OVERLAY 10 Hz Figure 3–18: Overlay Eye display 3–20 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 78 Gain is enabled, a “>” appears in front of the deflection factor to indicate the uncalibrated condition. 3–21 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 79 1. Perform the initial settings for Eye measurements described on page 3–22. 2. Select the desired input channel (SER A or B). 3–22 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 80 5. Aberrations at the top or bottom line should not exceed 10% of the signal amplitude. 3–23 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 81 .8nS 1 kHz 100% –.1 –.2 –.3 Figure 3–21: Timing Cursors alignment for measuring 20–80% rise time 3–24 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 82: Table 3-1: List Of Measured And Actual Rise Times For The Waveform Monitor

    1.1 ns 1.3 ns 1.2 ns 1.4 ns 1.3 ns 1.5 ns 1.4 ns 1.6 ns 1.5 ns 3–25 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 83 Reference jitter transferred by genlocks into a serial system is typically between 20 and several hundred hertz. Also, the phase detection process used by the 3–26 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 84 Filter menu is not displayed). Leaving the FILTER menu returns the monitor to the unfiltered (FLAT) setting. 3–27 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 85 When you quit the Gain menu, Variable gain returns to the calibrated setting and Vertical gain returns to X1. 3–28 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 86 Legal G and R space +700 mV X–Y plot Diamond plot Figure 3–22: Construction of the Diamond display 3–29 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 87 B – Ok B > 700 mV B < 0 mV Figure 3–23: Out-of-gamut signals on a Diamond display 3–30 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 88 Y Ampl –300 mV | C | C Ampl Figure 3–24: NTSC and PAL Arrowhead gamut displays 3–31 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 89 A properly adjusted signal should be centered in the arrowhead graticule and have transitions that approach all the limits. 3–32 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 90 In addition, pin 16 of the Remote rear panel connector is pulsed low. Refer to Remote Connector discussion on page B–2 for more information. 3–33 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 91 75% color difference signals. 100% color difference signals extend from the baseline (0 V) to 700 mV, centered on the 50% graticule line. 3–34 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 92 K–factor graticule. You can expand the waveform by setting Gain to X5. The K factor graticule lines then measure 0.8% and 0.4% K factor. 3–35 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 93 500 ns per major division for 1-Line sweep and 1 s per major division in 2-Line sweep. Use the HORIZ POS knob to view the waveform extremes when magnified. 3–36 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 94 Wideband p-p jitter Jitter waveform after the high-pass filter Figure 3–27: Example of the Jitter display 3–37 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 95 Use the Voltage Cursors to measure specific parts of the jitter waveform. The Jitter Config menu READOUT selection determines the units for the Voltage Cursors. 3–38 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 96 Parade mode, then switch to the Digital Waveform mode and see the SAV value in the data stream. 3–39 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 97 To turn off the function press the LINE SEL menu button when the menu readout is displayed; press LIN SEL twice when the menu is not displayed. 3–40 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 98 CH 1 is from line n, CH 2 is from line n+1, and CH 3 is from line n+2. 3–41 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 99 To adjust the Picture display, press the CRT MENU button and use the CON- TRAST and BLACK LEVEL bezel knobs. 3–42 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 100 3. When you are done, press the ACCEPT button to lock the selection. 4. Press the RETURN bezel button to return to the PRESET menu. 3–43 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 101: Serial Status

    CABLE selection. Press the SERIAL button to exit the Serial format display. 3–44 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 102 The table on the Status screen contains EDH (SMPTE RP-165) and CRC error detection results. The elapsed time indicates the sample period for the error detection readout. 3–45 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 103 Reset. Sets the elapsed time back to zero and clears any detected EDH errors. Display. (WFM 601E and WFM 601M only) Selects either STATUS, FORMAT, or CABLE screens. 3–46 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 104 To get an accurate measurement, you must select the correct CABLE TYPE for your installation. 3–47 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 105 Field Length. Indicates an error if there are an incorrect number of lines in a field. ANC Parity. Indicates an error if a parity error has occurred in ancillary data. 3–48 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 106 CABLE LOSS. Displays the approximate loss of power due to the cable. To get an accurate measurement, you must select the correct CABLE TYPE for your installation. 3–49 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 107 EDH data is on lines 9 and 272 and, for 625 line standards, on lines 5 and 318. If your source can not insert EDH, use an alternative source, such as the Tektronix TSG-422 Option 1S Generator. This substitution is effective because sources must generate standard waveforms.
  • Page 108 No. The flag indicates only that one or more errors occurred. 3–51 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 109: Sweep

    HORIZ POS bezel knob to pan left and right on the waveform. Timing Cursors operate correctly in the magnified mode, though one or both may be off screen during measurement. 3–52 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 110: Vector Display Modes

    (radial dimension of amplitude) towards the color point. Pr signal Pb signal Figure 3–36: Vector display relationship of the Pr and Pb signals 3–53 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 111 3–54 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 112 Y signal Clamp point Black – Luminance (Y) White (R-Y) signal Figure 3–38: Construction of the Lightning display 3–55 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 113 (bending of the green/magenta transitions). Figure 3–39 shows the graticule and the measurement targets and timing delay scales. 3–56 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 114 , and P for each of the eight primary colors much better than the Parade display mode. 3–57 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 115: Video In

    Horizontal and vertical magnification are available by pressing the MAG and GAIN buttons. Magnification is also valid during cursor measurements. 3–58 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 116: Appendices

    Appendices Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 117 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 118: Appendix A: Specifications

    Appendix A: Specifications Table A–1 lists the Electrical specifications for the WFM 601A, WFM 601E, and WFM 601M Serial Digital Component Waveform Monitors. Performance Requirements are generally quantitative and can be tested by the Performance Verification Procedure in the Service Manual. Reference information describes useful operating parameters that have typical values.
  • Page 119 500 ps (20-80%), 775 ps (10-90%) Aberrations < 10%, 800 mV step Time Base Jitter < 200 ps peak-to-peak A–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 120 10 kHz to 5 MHz 100 kHz to 5 MHz Timing JItter 10 Hz to 5 MHz Jitter Waveform Accuracy A–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 121 CRT readout. Error Statistics Asynchronous errored seconds. Active picture and full field statistics are separately compiled. A–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 122 Absolute Maximum Input Voltage –8.5 V to +8.5 V, DC plus peak AC DC Input Impedance 20 k A–5 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 123 1.0 MHz Horizontal to Vertical Bandwidth 2 at 500 kHz and 2 MHz Matching Vertical Gain Accuracy A–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 124 34 dB at 2.5 MHz Accuracy Interchannel Timing Match 2.0 ns Picture Monitor Outputs Signal Format EBU/N10 or RGB, menu selectable. A–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 125: Table A-2: Crt Display

    Trace Rotation Range > 1 from horizontal Total adjustment range is typically Graticule Internal with variable illumination A–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 126: Table A-3: Ac Power Source

    Depth: 460.4 mm (18.125 in) Weight Net: 3.8 kg (8 lbs) Shipping: 7.2 kg (15.7 lbs) approximate A–9 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 127: Table A-6: Safety Standards

    Pollution Degree Pollution Degree 2: Do not operate in environments where conductive pollutants may be present. A–10 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 128: Table A-8: Certifications And Compliances

    Safety requirements for electrical equipment for measurement, control, and laboratory use Use high-quality shielded cables. When installed in any of the following Tektronix instrument enclosures: 1700F00 (Tektronix part number 437–0100–04) 1700F02 (Tektronix part number 437–0018–07) 1700F05 (Tektronix part number 437–0095–04) A–11...
  • Page 129 Appendix A: Specifications A–12 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 130: Appendix B: Remote Operation

    Eight of the Presets (stored front-panel settings) can be stored or recalled remotely. B–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 131: Table B-1: Remote Connector Pin Assignments And Functions

    No connection allowed Ground TTL ground +Y Audio Input Audio input, +8 V peak (WFM 601A Only) The +Y and –Y inputs can function as differential inputs for a common signal. –Y Audio Input Audio input, –8 V peak (WFM 601A Only)
  • Page 132 Preset 1 memory location to store the current front-panel settings. See the pin 25 description. B–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 133 STORE s is low, the current front-panel PRESET settings are stored in that Preset location. B–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 134: Appendix C: Remote Command Set

    In the following command descriptions, queries are given below the command syntax C–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 135 Appendix C: Remote Command Set in the Syntax sections. Query examples and typical responses are given in the Response sections. C–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 136: Cable Measurement Commands

    Examples slm:cab b1694 Returns slm? :SLM:LEVEL 4.75 dB;LENGTH 20 Meters;CABLE B1694; SOURCE 95 PERCENT slm:cab? :SLM:CABLE B1694 C–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 137: Slm:source? (Wfm 601E And Wfm 601M Only

    SLM:CABLE to indicate the cable type you are using. Syntax SLM:[RCVR]? Arguments None Examples slm:rcvr? Returns :SLM:RCVR 2 dB C–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 138: Slm:level? (Wfm 601E And Wfm 601M Only

    This command works for firmware version V1.X and V2.X. Syntax SLM[:LENGTH]? Arguments None Examples slm:length? Returns SLM:LENGTH 20 METERS C–5 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 139: Configuration Commands

    REFErence: MODE <INT | EXT> REFErence: MODE? Arguments <INT | EXT> Examples refe:mode int Returns refe:mode? :REFERENCE:MODE INTERNAL C–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 140: Arrowhead:limit:pal

    Arguments <IRE_100 | IRE_110 | IRE_120 | IRE_131> Examples arrow:limit:ntsc ire_120 arrow:limit:ntsc ire_131 Returns arrow:limit:ntsc? :ARROWHEAD:LIMIT:NTSC IRE_131 C–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 141: Arrowhead:format

    GAMut:GRATicule <ARROWhead | DIAmond> GAMut[:GRATicule]? Arguments <ARROWhead | DIAmond> Examples display:single gamut gam:grat dia Returns gam:grat? :GAMUT:GRATICULE DIAMOND C–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 142: Gamut:alarm:trigger

    GAMut:ALarm:DISPlay <SCRN | PICT | BOTH> GAMut[:ALarm | :ALarm:DISPlay]? Arguments <SCRN | PICT | BOTH> Examples gam:al:disp pict Returns gam:al:disp? :GAMUT:ALARM:DISPLAY PICT C–9 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 143: Standard

    Syntax VECtor:BARS <B100 | B75> VECtor[:BARS]? Arguments <B100 | B75> Examples vec:bars b75 Returns vec:bars? :VECTOR:BARS B75 C–10 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 144: Vector:graticule

    Arguments <STATUS | FORM | CABLE> Examples menu serial serial:menu form ser:menu status Returns ser:menu? :SERIAL:MENU STATUS C–11 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 145: Serial:display

    SERial:MONitor <GBR | YPbPr> SERial[:MONitor]? Arguments <GBR | YPbPr> Examples ser:mon gbr SERIAL:MON YPBPR Returns ser:mon? :SERIAL:MONITOR YPBPR C–12 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 146: Serial:eavsav

    Syntax SERial:ALarm:<error type> <alarm setting> SERial[:ALarm | :ALarm:<error type>]? Arguments :<error type> <alarm setting> C–13 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 147: Uimenu:

    PREset functions, and clear the menu display. Table C–3 lists the UIMENU (User Interface menu) commands and argument options. Syntax UIMENU:<command> <options> UIMENU[:<command>]? Arguments :<command> <options> C–14 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 148: Table C-3: Uimenu: Commands And Options

    Returns uimenu? :UIMENU:STICKY FILTER;PRESET OFF;CONFIG ON;CONFIGFCT ON;CONFIGSEL WFMVEC;CRTADJUST TRACE uimenu:preset? :UIMENU:PRESET OFF C–15 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 149: Cursor Commands

    <VOLT | TIME | VOLT_TIME | MARK | NONE> Examples cur:sel volt cur:select mark cursor:select volt_time Returns cur? :CURSOR:SELECT VOLT_TIME;CONTROL TIME cursor:select? :CURSOR:SELECT VOLT_TIME C–16 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 150: Cursor:control

    Arguments :<ONE | TWO | THREE> <marker position> Examples mc:three1838 mc:one 1200 Returns :MCURSORS:ONE 1200;TWO 2025;THREE 1838 C–17 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 151: Vc | Tc>:

    <timing range> 0 – 4000 Examples vc:one 3000 tc:two 2136 tc:one 1000 Returns :TCURSORS:ONE 1000;TWO 2136;DIFFERENCE 1136;TRACK OFF C–18 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 152: Tc | Vc>:Track

    Moving TC:ONE causes TC:TWO to move the same amount. Examples vc:track on tc:track off Returns tc:track? :TCURSORS:TRACK OFF C–19 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 153: Digital Waveform And Digital List Commands

    ACTIVE;DATA:V0 528;V1 528;V2 528;V3 532;V4 532;V5 532;V6 532;V7_SELECTED 536;V8 536;V9 536;V10 536;V11 540;V12 540;V13 540;V14 540;:DGTL:VDATA:SELECTED 532;CB 536;Y0 536;CR 536;Y1 536 C–20 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 154: Dgtl:region? (Wfm 601M Only

    Change the display mode to Digital List using the DISPlay:SINGLE <display mode> command (page C–25) before using this command. C–21 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 155: Dgtl:vdata? (Wfm 601M Only

    C–25) before using this command. Syntax DGTL:VDATA? Arguments None Examples disp:single:dwfm dgtl:vdata? Returns dgtl:vdata? :DGTL:VDATA:SELECTED 536;CB 536;Y0 536;CR 536;Y1 536 C–22 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 156: Dgtl:vidmode

    Syntax DGTL:FREEZE <ON | OFF> DGTL[:FREEZE] Arguments <ON | OFF> Examples dgtl:freeze on Returns dgtl:fr? :DGTL:FREEZE ON C–23 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 157: Dgtl:base (Wfm 601M Only

    DGTL:BASE <HEX | DECIMAL | BINARY> DGTL[:BASE]? Arguments <HEX | DECIMAL | BINARY> Examples dgtl:base hex Returns dgtl:base? :DGTL:BASE HEX C–24 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 158: Table C-6: Display:single Commands

    Use for the WFM 601E only. JITter Jitter Use the JITter commands to set jitter measurement parameters (page C–40). C–25 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 159 DISPlay:INTENSITY:<display mode>:<line select mode> <intensity> DISPlay[:INTENSITY | :INTENSITY:<display mode> | :INTENSITY:<display mode>:<line select mode>]? Arguments :<display mode>:<line select mode> <intensity> C–26 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 160: Table C-7: Display:intensity Command Options

    –2047 to 1700. Syntax DISPLay:INTENSITY:READ <intensity> DISPLay[:INTENSITY | :INTENSITY:READ]? Arguments <intensity> Examples displ:intensity:read 700 Returns display:intensity:read? :DISPLAY:INTENSITY:READ 700 C–27 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 161 –300. A setting less than zero can produce a light picture, while settings greater than 100 can produce a dark picture. This setting corre- C–28 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 162 <scale> is 0 and the lowest is –2047. The best value depends on the brightness of the environment. Syntax DISPlay:SCALEillum <scale> DISPlay[:SCALEillum]? C–29 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 163: Table C-8: Display:focus Command Options

    –2047 to +2047. –2047 to +2047. Examples DISPLAY:FOCUS:H1 2047 disp:focus:norm 100 Returns display:focus? :DISPLAY:FOCUS:NORMAL 100;H1 2047;H15 2047 C–30 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 164 If an error was detected, use ALLEV? to help you determine the possible cause of the error. C–31 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 165: Table C-9: Typical Allev? Responses To Detected System Errors

    :ESR 32 Returns allev? :ALLEV 104,”Data type error; invalid character data–n:var:vert:value ON\0A” See Table C–9 for additional examples. C–32 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 166 Syntax EYe:MODE <OVERLAY | EYE10> EYe[:MODE]? Arguments <OVERLAY | EYE10> Examples eye:mode eye10 Returns eye:mode? :EYE:MODE EYE10 C–33 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 167 <E10HZ | E100HZ | E1000HZ> Examples eye:clo e1000hz Returns eye? :EYE:DISPLAY EQEYE;MODE EYE10;CLOCKHPF E1000HZ (WFM 601M) :EYE:MODE EYE10;CLOCKHPF E1000HZ (WFM 601E) C–34 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 168 The commands in this section allow you to select fixed gain levels or set variable gain levels for the Waveform, Vector, and Lightning displays. GAIN:AUDIO <DBU0 | DBU4 | DBU8 | DBU12> (WFM 601A Only) Sets the gain level of the analog audio input to the desired level and scales the electronic graticule accordingly.
  • Page 169 GAIN:<WFM | VEC>:VAR:VALUE? Arguments <WFM | VEC> and <gain> Examples gain:vec:var:value 950 Returns gain:vec:var? :GAIN:VECTOR:VARIABLE:STATE ON;VALUE 950 C–36 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 170 Arguments <VERT | HORZ> and <gain> Examples gain:ltng:var:vert:state on gain:ltng:var:vert:value 2000 Returns gain:ltng:var:vert? :GAIN:LTNG:VAR:VERT: STATE ON;VALUE 2000 C–37 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 171 Syntax INput:SOUrce <SERIALA | SERIALB> INput[:SOUrce]? Arguments <SERIALA | SERIALB> Examples in:sou seriala Returns input:sou? :INPUT:SOURCE SERIALA C–38 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 172 INput:PBPROFFSet <MV_0 | MV_350> INput[:PBPROFFSet]? Arguments <MV_0 | MV_350> Examples input:pbproffset mv_0 Returns :INPUT:SOURCE SERIALA; CHANNEL CH1,CH2; PBPROFFSET MV_0 C–39 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 173 JITter:UNITS <SEC | UI | OFF> JITter[:UNITS]? Arguments <SEC | UI | OFF> Examples jit:units OFF Returns jit:units? :JITTER:UNITS OFF C–40 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 174 Syntax JITter:<ALIGNMENT | TIMING >? Arguments <ALIGNMENT | TIMING > Examples jit:timing? Returns jit:timing? :JITTER:TIMING 0.10 UI C–41 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 175: Table C-10: Lineselect: Commands And Options

    Line Select. Select the line with the command LINES:NUMBER and the field with LINES:FIELD. C–42 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 176 Line Select Commands Examples lines:mode on Returns lines? :LINESELECT:MODE ON;NUMBER 573;SMPL 741;FIELD F2;FMODE TWO;DISPLAY SAMPLE C–43 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 177 POSITion:<VERTical | HORZ>:<display mode> <range> POSITion[:<VERTical | HORZ> | :<VERTical | HORZ>:<display mode>]? Arguments <display mode> <range> C–44 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 178: Table C-11: Position:vertical Commands And Options

    Positions the Audio display horizontally. (WFM 601A only) Examples pos:vertical:EYe 100 Returns pos:horz:eye? :POSITION:HORIZONTAL:EYE 0 pos:vert:ey? :POSITION:VERTICAL:EYE 100 C–45 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 179 1 and 9. (The waveform monitor can store 9 presets in addition to the FACTORY preset.) Syntax PREset:STORE <PRESETn> Arguments <PRESETn> Examples preset:store preset1 Returns None C–46 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 180 Appendix B for more information on using the REMOTE connector. Syntax PREset:NAMES:<PRESETn> “any string” Arguments :<PRESETn> “any string” Examples preset:names:preset5 “jit–meas” preset:names:preset1 “clock–meas” Returns None C–47 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 181 SWEEP:TIMING <ONEL | TWOL | ONEF | TWOF> SWEEP[:TIMING]? Arguments <ONEL | TWOL | ONEF | TWOF> Examples sweep:timing twol Returns sweep:timing? :SWEEP:TIMING TWOLINE C–48 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 182 SWEEP:MAG <ON | OFF> SWEEP[:MAG]? Arguments <ON | OFF> Examples sweep:mag off Returns sweep? :SWEEP:TIMING ONEFIELD; MAGNIFY OFF C–49 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 183 <FILTer | CURsor | LINESelect | CONFIG | GAIN | CRT | CLear | SERial> Examples menu lines menu config menu ser menu cl Returns menu? :MENU CLEAR C–50 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 184: Table C-13: Filter Command Options

    AFC should be on except when large, low-frequency jitter is present in your system. Syntax AFC <ON | OFF> AFC? Arguments <ON | OFF> C–51 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 185 ROTEST <ON | OFF> ROTEST? Arguments <ON | OFF> Examples rotest off rotest on Returns rotest? :ROTEST ON C–52 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 186 Syntax CALSignal:ENable <OFF | ON> CALSignal[:ENable]? Arguments <OFF | ON> Examples cals:en OFF Returns cals? :CALSIGNAL:ENABLE OFF C–53 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 187 System Commands C–54 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 188 This procedure expects a character string to send and places to put two types of responses: expected and unexpected. C–55 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 189 Remote Command Processing Code C–56 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 190 Remote Command Processing Code C–57 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 191 Remote Command Processing Code C–58 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 192 Remote Command Processing Code C–59 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 193 Remote Command Processing Code C–60 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 194 Remote Command Processing Code C–61 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 195 Remote Command Processing Code C–62 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 196: Wfm 601A, Wfm 601E & Wfm 601M User Manual

    This section describes preventive maintenance for the waveform monitor and how to replace graticule light bulbs. If the waveform monitor does not function properly, send it to a qualified service personnel or contact Tektronix for service. Cleaning or Replacing the Fan Filter To ensure adequate air flow, clean or replace the rear-panel fan filter regularly.
  • Page 197 CRT. You or a service person can replace these bulbs if they burn out. The Accessories kit shipped with your waveform monitor contain several replacement bulbs. Additional bulbs can be purchased from Tektronix or from local electronics distribution sources.
  • Page 198 2. Using the Allen wrench, loosen the set screws in the five knobs below the CRT; then remove the knobs. D–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 199 9. Replace the five knobs below the CRT and tighten the set screws. D–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 200 Glossary Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 201 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 202 (Decibel) A logarithmic unit used to describe signal ratios. For voltages, dB = 20 Log Glossary–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 203 Glossary–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 204 Red, Green, and Blue. Also referred to as GBR in SMPTE specifications. The three primary colors used in color television’s additive color reproduc- Glossary–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 205 Waveform Monitor A specialized oscilloscope that plots voltage versus time to evaluate television signals. See Luminance. Glossary–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 206 Index Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 207 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 208 3–9 SER ARM description, 3–11 WFM/VEC description, 3–9 Connector Cabinetizing, 1–8 compatibility, 1–14 Cabinets, 1–5 Index–1 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 209 3–15 EQ EYE mode, 3–19 FLAT mode, 3–19 Video and Data modes, 3–14 Index–2 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 210 GAIN CAL, configuration menu, 3–12 POWER, 2–5 GAMUT REF, 2–4 configure menu, 3–10 saving settings, 3–43 in Configure GAMUT menu, 3–10 Index–3 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 211 1–12 LPASS, Filter menu selection, 3–27 installing in a rack, 1–9 Luminance, Glossary–3 line termination, 1–13 Index–4 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 212 MON OUT Option A3, 1–3 configuring as GBR or YPbPr, 3–11 Option A4, 1–3 Format Configure menu, 3–11 Index–5 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 213 SERial:MENU, C–11 ARROWhead:LIMIT:NTSC, C–7 SERial:MONitor, C–12 ARROWhead:LIMIT:PAL, C–7 SLM:CABle, C–3 buffering code, C–55 SLM:LENGTH?, C–5 CALSignal:ENable, C–53 Index–6 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 214 Serial B input, Loop-through input, 2–7 75 ohm terminator, 1–2 Serial channel measurements Shipping instrument, 1–10 aberrations, 3–23 Index–7 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 215 Waveform display, using Line Select, 3–58 Overlay mode for Eye Pattern, 3–20 Waveform graticule 2T Pulse to Bar, special graticule, 3–36 Index–8 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 216 WFM AS, in Configure WFM/VEC menu, 3–9 WFM/VEC, configure menu, 3–9 Word correlated behavior, serial channel measurements, YPbPr Parade, 3–41 3–27 Index–9 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 217 Index Index–10 WFM 601A, WFM 601E & WFM 601M User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

This manual is also suitable for:

Wfm 601eWfm 601m

Table of Contents
