- Page 1 USB to CAT Extender English | 简体中文 Quick Start Guide V1.0 Copyright©2021 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.All rights reserved.
-
Page 2: Package Contents
Package Contents Extender (Transmitter) Extender (Receiver) Interface Protective Cover 3M Velcro×2 Power Adapter (48V/0.7A) Quick Start Guide Note: We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in poor performance. - Page 3 Interface Protective Cover Attachment 1. Remove the bottom cover . 2. Connect the cables and attach the interface protective cover. Extender (Receiver)
- Page 4 Connection Scene 1: Extend the length of your USB peripheral signal USB peripherals Extender (Transmitter) (for example, USB camera or speaker) Ethernet cable MCore Extender (Receiver) Power Adapter Scene 2: As an adapter for MTouch Ⅱ to connect to a third-party mini-PC Extender (Transmitter) Ethernet cable Mini-PC...
- Page 5 包装清单 延长线盒子 （发送端） 延长线盒子 （接收端） 接口保护罩 3M 魔术贴 ×2 电源适配器（48V/0.7A） 快速入门指南 说明：我们推荐使用由亿联提供或经亿联认可的配件， 使用未经认可的第三方配件可能会导致性能的下降。...
- Page 6 安装接口保护罩 1. 拆开接口保护罩 2. 连接线材并安装接口保护罩 延长线盒子（接收端）...
- Page 7 连接 场景 1: 延长 USB 外设信号的传输距离 USB 外设 （如 USB 摄像头 , USB 扬声器等） 延长线盒子 （发送端） 网线 MCore 延长线盒子（接收端） 电源适配器 场景 2: 作为 MTouch Ⅱ连接第三方 mini-PC 的转接器 延长线盒子 （发送端） 网线 Mini-PC MTouch Ⅱ 电源适配器 说明：网线需额外购买。我们推荐购买长度不超过 40 米的 CAT5/CAT5e/CAT6 网线。...
-
Page 8: Declaration Of Conformity
YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD Address: 309, 3rd Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R.C Manufacturer: YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD Address: 309, 3rd Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R.C DATE: 29th /Jan/2021... - Page 9 We are not liable for damage or loss resulting from the use of this product, or for any claim from a third party. We are not liable for problems with Yealink device arising • Before cleaning the device, disconnect it from the power supply.
-
Page 10: Need More Help
Need more help? Yealink Documentation& Video YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD. Web: www.yealink.com 430104001527 Copyright©2021 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.All rights reserved.
