Quick Installation Guide
Section 1
Install Driver & Utility Software
1
Step 1
Before installing the utility software, DO NOT insert the USB
adapter into your computer. If the adapter is inserted already, Windows
will detect the adapter and request for a driver. Click Cancel to quit the
wizard and remove the USB adapter from your computer.
Step 2
Close all programs that are currently running. Insert the provided
Driver & Utility CD into your CD-ROM drive and click Install Software from
the setup menu. See Fig. 1.1.
Note: If the setup menu does not automatically appear, go to Start,
Run, and type D:\Autorun.exe (where D is the letter of your CD-
ROM drive) and click OK.
Model # AWLL017
Package Content:
802.11b USB Adapter
USB Extension Cable
Driver & Utility CD
Quick Installation Guide
Ver. 5A
Step 3
Click Next at the InstallShield Wizard screen. See Fig 1.2.
Step 4
Click Next to accept the default destination folder or click
Browse to select a destination location.
Note: Screen shots are for Windows XP
Fig 1.1
Fig 1.2
Advertisement
Table of Contents
Related Manuals for Airlinkplus AWLL017
Summary of Contents for Airlinkplus AWLL017
-
Page 1: Quick Installation Guide
Quick Installation Guide Model # AWLL017 Section 1 Install Driver & Utility Software Step 1 Before installing the utility software, DO NOT insert the USB adapter into your computer. If the adapter is inserted already, Windows will detect the adapter and request for a driver. Click Cancel to quit the wizard and remove the USB adapter from your computer. - Page 2 Step 5 Click Next to accept the default program folder name. Step 6 Click Finish to complete the driver and utility installation. Step 7 Restart the computer if you are prompted to do so. Section 2 Install USB Adapter Step 1 After the computer is restarted, insert the USB adapter into the computer’s USB port.
- Page 3 Note to Windows XP Users Only Windows XP provides a built-in Wireless Zero Configuration Utility for configuring and monitoring wireless devices on your computer. When it is enabled, it will override the Wireless Configuration Utility. To disable the Windows XP Wireless Zero Configuration Utility and have the Wireless Configuration Utility manage your USB adapter, perform the following steps: Step 1 Double-click the Windows XP network icon and click Advanced (or...
-
Page 4: Technical Support
Key 1 for all the clients and/or access points in your wireless network. For more advanced features and additional details, please refer to the User’s Manual on the provided CD-ROM. Section 4 Technical Support Email: support@airlinkplus.com Toll free: 1-888-746-3238 Website: www.airlinkplus.com...
