Quick Installation Guide

Section 1

Connecting the Router

Note: Prior to connecting the router, be sure to power off your computer, DSL/Cable
modem, and the Wireless Router.
Step 1
Connect one end of a network cable to the WAN port of the Wireless Router
and connect the other end of the cable to the DSL/Cable modem.
Step 2
With another network cable, connect one end of the cable to your computer's
network card and connect the other end to one of the LAN ports of the Wireless
Router.
Step 3
Power on the DSL/Cable Modem.
Step 4
Power on the Wireless Router by connecting one end of the supplied power
adapter to the power jack of the Wireless Router and connecting the other end to an
electrical outlet.
Step 5
Power on your computer.
Model # ARW027
Package Contents:
Wireless Router
Power Adapter
Quick Installation Guide
User's Manual
The following figure illustrates a connection example:
Section 2
Configuring Network Clients
Before configuring the Wireless Router, you must configure the network clients in order
to establish proper connection with the router. The router has a default IP address of
192.168.1.1 and a subnet mask of 255.255.255.0. Follow the steps below according to
your operating system to configure your network clients.
Step 1
For Windows 2000/XP:
Right-click My Network Places on the desktop and select
Properties. Right-click Local Area Connection and select Properties.
For Windows 95/98/ME:
Right-click Network Neighborhood or My Network Places
on the desktop and select Properties.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARW027 and is the answer not in the manual?

Questions and answers

Related Manuals for Airlinkplus ARW027

Summary of Contents for Airlinkplus ARW027

  • Page 1: Quick Installation Guide

    Quick Installation Guide Model # ARW027 Section 1 Connecting the Router Note: Prior to connecting the router, be sure to power off your computer, DSL/Cable modem, and the Wireless Router. Step 1 Connect one end of a network cable to the WAN port of the Wireless Router and connect the other end of the cable to the DSL/Cable modem.

  • Page 2: Configuring The Wireless Router

    Note: Screen shots are for Windows 2000/XP Step 2 For Windows 2000/XP: Select Internet Protocol (TCP/IP) and click Properties. For Windows 95/98/ME: Select TCP/IP-> “Your Ethernet Adapter” and click Properties. Step 3 For Windows 2000/XP: Select Obtain an IP address automatically and Obtain DNS server address automatically, and click OK.
  • Page 3 Step 4 Select your time zone. You can also configure the optional Daylight Saving time. Click Next to go the next page. Step 5 Set the desired SSID, Country (Domain Regulatory), Channel, and WEP settings of the Wireless Router and click Next. Note: Your wireless adapter must have the same settings in order to establish proper wireless connection.

  • Page 4: Technical Support

    System Light on the front panel of the router to start blinking. Congratulations! You have successfully configured your Wireless Router. For more detailed information on advanced setups, please refer to the User’s Manual. Section 4 Technical Support E-mail: support@airlinkplus.com Toll Free: 1-888-746-3238 Web Site: www.airlinkplus.com P/N: 1907WLB22037051...
