General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... PVC, Super, or Crazy Glue
... Hammer or Rubber Mallet
... Straight Blade Screwdriver
with #2 phillips bit
(recommended)
(if combining trellis with planter)
Camelot Trellis
11140 (M)
Model#
Part #
1
2" sq. x 59½ Left Post
2
2" sq. x 59½ Right Post
3
⅞ x 1½ x 27½" Center Cross Rail
4
⅞ x 1½ x 27½" Bottom Cross Rail
5
1 x 1 x 58" Vertical Rail
6
1 x 1 x 55" Vertical Rail
7
14" Ground Anchor
8
Hardware Bag
2" sq." Post Cap
1 x 1" Arrowhead Cap
¾" Painted Screw
#8 - 1" Painted Self Tapping Screw
(for ground anchors)
115 Vision Parkway
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
8
1
1
2
2
1
2
3
6
4
1
Advertisement
Table of Contents
Related Manuals for DuraTrel Camelot Trellis
Summary of Contents for DuraTrel Camelot Trellis
- Page 1 Camelot Trellis 11140 (M) Model# Assembly Instructions Part # Description 2" sq. x 59½ Left Post 2" sq. x 59½ Right Post ⅞ x 1½ x 27½" Center Cross Rail ⅞ x 1½ x 27½" Bottom Cross Rail 1 x 1 x 58" Vertical Rail 1 x 1 x 55"...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out right post (part 2). Starting at bottom (6" from bottom) insert bottom cross rail (part 4) and center cross rails Slide left post (part 1) over corresponding cross rails. Insert 58” vertical rail (part 5) through center hole of cross rails. Camelot Trellis...
- Page 4 2" sq. post caps of one long side of the planter and slide trellis over the planter legs. Using two 1" painted self-tapping screws from trellis ground anchor kit (part 8), fasten trellis to planter. Camelot Trellis...
- Page 5 Be sure that ground anchors are straight and in accordance with measurements of trellis/arbor posts. Allow cement to dry. NOTE: There is very little room for error with this installation method. Slide trellis/arbor over ground anchors. Using two 1" self-tapping screws per post, screw the post to the Camelot Trellis...
