General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... PVC, Super, or Crazy Glue
... Hammer or Rubber Mallet
... Straight Blade Screwdriver
with #2 phillips bit
(recommended)
(if combining trellis with planter)
Camelot Trellis
11140 (M)
Model#
Part #
1
2" sq. x 59½ Left Post
2
2" sq. x 59½ CMT Right Post
3
⅞ x 1½ x 27½" Center Cross Rail
4
⅞ x 1½ x 27½" Bottom Cross Rail
5
1 x 1 x 58" Vertical Rail
6
1 x 1 x 55" Vertical Rail
7
Hardware Bag
2" sq." Post Cap
1 x 1" Arrowhead Cap
¾" Painted Screw
8
Trellis Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
1
1
8
1
1
2
1
2
3
6
1
2
4
1
