max 5 x 3.5
General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
with #2 phillips bit
(recommended)
Camelot Arbor
11141
Model#
Part #
1
2" sq. x 84" Left Post
2
2" sq. x 84" Right Post
3
⅞ x 1½ x 27½" Center Cross Rail
4
⅞ x 1½ x 27½" Bottom Cross Rail
5
1 x 1 x 63" Vertical Rail
6
1 x 1 x 60" Vertical Rail
7
1½ x 4 x 72" Arbor Top Rail
8
⅞ x 1½ x 41" Arbor Top Cross Rail
9
⅞ x 1½ x 18" Corner Brace
10
5 ⅜" Arbor Top End Cap
11
Hardware Bag
2" sq." Post Cap
1 x 1" Arrowhead Cap
⅞ x 1½" End Cap
1¼" Painted Screw
¾" Painted Screw
Super Glue Tube
12
Arbor Ground Anchor Kit
16" Steel Ground Anchor (L-Shaped)
#8 - 1" Painted Self Tapping Screw
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
(includes:)
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
2
2
18
2
2
4
2
8
4
4
1
4
6
16
28
12
1
1
4
8
1
Advertisement
Related Manuals for DuraTrel Camelot Arbor
Summary of Contents for DuraTrel Camelot Arbor
- Page 1 Camelot Arbor 11141 Model# Assembly Instructions Part # Description 2" sq. x 84" Left Post max 5 x 3.5 2" sq. x 84" Right Post ⅞ x 1½ x 27½" Center Cross Rail ⅞ x 1½ x 27½" Bottom Cross Rail 1 x 1 x 63"...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 4) and nine center cross rails (part 3). Slide one left post (part 1) over corresponding cross rails. Insert one 63” vertical rail (part 5) through center hole of cross rails. Insert two 55” vertical rails (part 6) through remaining holes in cross rails. Camelot Arbor...
- Page 4 Using included super glue, glue arrowhead caps onto vertical rails. REPEAT steps 1-6 for second arbor panel Using super glue, glue ⅞ x 1½" end caps one each end of eight 41" arbor top cross rails (part 8). Camelot Arbor...
- Page 5 For each post, measure from tip of each arbor top rail to outside of post and move post so it is 9 inches from end of arbor top rails. Using three 1¼" screws per post, fasten together post, arbor top rail and corner brace. Camelot Arbor...
- Page 6 Using 1¼” screws, screw remaining two arbor top cross rails with caps to arbor top panels. Using super glue tube, glue four arbor top end caps (part 10) onto ends of arbor top rails. Glue four 2" sq. post caps onto post tops. Camelot Arbor...
- Page 7 Camelot Arbor 11141 2" sq. x 84" CMA Left Post 2.00 2" sq. x 84" CMA Right Post 2.00 ⅞ x 1½ x 27½" CM Center Ra 18.00 ⅞ x 1½ x 27½" CM Bottom Ra 2.00 1 x 1 x 63" Rail 2.00...
