- Page 1 Power Unlocked by Design SAFETY, INSTALLATION, AND OPERATIONS MANUAL (United States and Canada) PowerXT -R Module ® Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
- Page 2 For warranty text refer to solaria.com/additional-product-information/ For Solaria patent information refer to solaria.com/patents/ © 2020 Solaria Corporation All rights reserved. Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
-
Page 3: Table Of Contents
4.0 Module Mounting ......................... 7 5.0 Maintenance ........................11 6.0 Disclaimer of Liability ......................11 7.0 Electrical Specifications ......................11 8.0 Mechanical Dimensions .......................12 Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020... -
Page 4: Introduction
The solar system, its components, and installation should be approved by the authorities having jurisdiction in the area. Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020... -
Page 5: Electrical Installation
Do not use modules of different electrical or physical configurations in the same DC string or inverter. y For field connections, Solaria recommends that all connecting cables be double insulated flexible copper (Cu) conductors with a minimum rating of 90°C. The cable size should be determined by the applicable codes but is recommended that this be no less than 4mm²... - Page 6 Refer to the NEC for additional multiplying factors that may be applicable. y All Solaria modules are equipped with connecting cables and locking connectors. Modules have been designed to be easily connected. The locking connectors are not to be disconnected under load. The proper procedure to disconnect the module locking connectors is as follows: Turn off the inverter(s), shut off the module DC disconnect(s) and then disconnect the locking connectors using an approved tool set.
-
Page 7: Module Mounting
3.2 Non Grid-Tied Applications y Contact Solaria for appropriate grounding guidelines. 4.0 Module Mounting The Solaria Limited Product Warranty is contingent upon modules being mounted in accordance to the requirements described in this section. 4.1 Site Considerations Solaria modules should be mounted in locations that meet the following requirements. - Page 8 For areas with heavy snow or when load is expected to be more than 2400Pa, rails supporting the bolted Š connections should run perpendicular to the length of the module. Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
- Page 9 CLAMP AREA B CLAMP AREA B 11in 279mm 152mm CLAMP AREA A 152mm CLAMP AREA A 11in 279mm Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020 UNLESS OTHERWISE SPECIFIED:...
- Page 10 CLAMP AREA A 11.4in 11.4in 290.0mm 290.0mm POWERXT-XXXR-PMX CLAMP AREAS Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020 UNLESS OTHERWISE SPECIFIED: DESCRIPTION NAME DATE DIMENSIONS ARE IN MM [IN] POWERXT-XXXR-...
- Page 11 South in Northern Hemisphere and they face North in Southern Hemisphere. 4.4 Module Orientation y Modules can be mounted in either “portrait” or “landscape” orientation. Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
-
Page 12: Maintenance
No license is granted by implication or otherwise under any patent or patent rights. y The information in this Manual is based on The Solaria Corporation knowledge and experience and is believed to be reliable; but such information, including the product specifications (without limitations) and suggestions, do not constitute a warranty, expressed or implied. -
Page 13: Mechanical Dimensions
4x 4.5mm [0.18in] Grounding Holes ‘A’ y 4x 7.0mm [0.28in] x 10.0mm [0.39in] Mounting Slots ‘B’ y Module Weight: 20 kg (44 lbs.) Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020... - Page 14 4x 4.5mm [0.18in] Grounding Holes ‘A’ y 4x 7.0mm [0.28in] x 10.0mm [0.39in] Mounting Slots ‘B’ y Module Weight: 21 kg (46 lbs.) Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
- Page 15 FINISH WITHOUT THE WRITTEN PERMISSION OF SCALE: 1:5 WEIGHT: 18.5 kg SHEET 3 OF 3 APPLICATION SOLARIA CORPORATION IS PROHIBITED. Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
- Page 16 Power Unlocked by Design Solaria USA 45700 Northport Loop East Fremont, CA 94538 United States of America T: +1-510-270-2507 www.solaria.com Safety, Installation, and Operations Manual © Solaria Corporation All rights reserved. Contents subject to change without notice. SOL-MAN-0002 Rev 09,12-2020...
