- Page 1 HopperOne S11 Pulse Parallel Operator’s manual Rev. 1.02 HopperOne S11 Pulse Parallel Operator’s Manual...
- Page 2 Alberici S.p.A. reserves the right to modify, without prior notice and in any way, any part of this manual and the technical specifications of this product, as part of the continuous pursuit of improvement of its products.
- Page 3 Sommario General description ..........................2 Main features ............................2 Electrical Features ..........................5 Operation .............................. 7 STORICO REVISIONI Revisione n° Data Modifica Note Creazione 1.00 21.09.05 Creazione HopperOne Rev. 1.01 16.04.16 Modifica testata e nome S11 Rev. 1.02 30.01.17 Sensori livello ottici...
-
Page 5: General Description
IN MOTION 2. Main features The HopperOne S11 cctalk is available in 2 different versions, according to the respective positions of the electrical connector and the coins outlet. When they are located at opposite sides, the version is named “STANDARD”; when they are located at the same side, the version is named “REVERSE”. - Page 6 2.1 Overall dimensions 2.2 Position of the Chinch connector Reverse version (connector located on the same side of the output of the coins) Standard version (connector located on the opposite side of the output of the coins)
- Page 7 2.3 Installation • fasten the slide support, • slide the hopper in • for electrical connections, please see chapter 3 92mm 92mm ø 5.5 mm 68.5mm 118mm 245mm Please use conical head bolts slide hopper in Base fixing plate of the hopper (included with the hopper) ALWAYS CONNECT THIS METAL PLATE TO THE...
-
Page 8: Electrical Features
Electrical Features All the signals handled by the hopper are in negative logic: each signal is considered active when its voltage is LOW (GND). 3.1 CINCH connector Pin-Out This connector is located at the right side (standard) or left side (reverse) of the hopper slide base. 3.2 Power Supply This equipment must be operated by +24V direct voltage. - Page 9 3.3 Input signals There are three available input signals: IN1 IN2 IN3 . Using these signals, it is possible to determine the mode of operation (see chapter 4), to reset the hopper and to start the dispensing. The equivalent pins are pin4 To select the type of operation pin8...
-
Page 10: Operation
4. Operation Determine in advance how your hopper must operate, since it will be necessary for you to choose the type of operation best suitable for your requirements. This hopper can work in three different modes, Type0 Type1 Type2 … 4.1 Selection of conditions The logic state of these inputs, that is, the operation mode that the hopper will be using, is detected only at power up or reset. - Page 12 Progettazione e produzione di sistemi di pagamento, accessori per videogames e macchine vending Design and manufacture of payment systems, accessories for videogames and vending machines Via Ca’ Bianca 421 http://www.alberici.net 40024 Castel San Pietro Tel. + 39 051 944 300 info@alberici.net...
