- Page 1 Manual Talc Applicator Hydraulic Talc I n s t a l l a t i o n K i t J&M Manufacturing Co, Inc 284 Railroad Street - P.O. Box 547 | Fort Recovery, OH 45846 | Ph: (419) 375-2376 | Fax: (419) 375-2708...
-
Page 3: Table Of Contents
Table of Contents 4 ..................To the Dealer 5 . -
Page 4: To The Dealer
To the Dealer Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists are completed before releasing equipment to the owner. The dealer must complete the Warranty Registration found on the Dealer Portal website located at dealer.jm-inc.com and return it to J&M Mfg. -
Page 5: General Information
General Information TO THE OWNER: The purpose of this manual is to assist you in operating and maintaining your Talc Applicator in a safe manner. Read it carefully. It furnishes information and instructions that will help you achieve years of dependable performance and help maintain safe operating conditions. -
Page 6: Bolt Torque Chart
Bolt Torque Chart Always tighten hardware to these values unless a different torque or tightening procedure is listed for specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware. Make sure fastener threads are clean and you start thread engagement properly. -
Page 7: Safety Rules
Safety Rules ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be erased by an operator’s single careless act. In addition, hazard control and accident prevention are dependent upon the awareness, concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment. -
Page 8: Talc Box Mount Assembly
Talc Box Mount Assembly STEP ONE - LC290 & LC390 • Bolt the LC290/LC390 talc box mounting bracket (JM0037272) to the SpeedTender’s front passenger side leg using two 3/8” x 1” flange screws and 3/8” flange nuts. Hand tighten fasteners. •... -
Page 9: Flex Flighting Assembly
Flex Flighting Assembly STEP ONE - SpeedTender Pro c4·50 • Bolt the SpeedTender Pro c4·50 talc box mounting bracket (JM0037645) to the SpeedTender’s front passenger side leg using four 3/8” x 1” flange screws and 3/8” flange nuts. Hand tighten fasteners. •... -
Page 10: Attaching Motor And Door Skirt
Attaching Motor and Door Skirt 1/4”-28 x 3/8” Hex Bolts STEP FOUR - All models • Align the motor shaft key with the keyway in the shaft coupler. • Attach the hydraulic motor (JM0042491) to the talc box using the three 1/4”-28 x 3/8” hex bolts and tighten. STEP FIVE - All models •... -
Page 11: Talc Pvc Tube Assembly
Talc PVC Tube Assembly STEP SEVEN - LC290, LC390 & SpeedTender Pro c4·50 • Attach the talc flighting PVC tube (LC390 - JM0042810, LC290 - JM0042809, SpeedTender Pro c4·50 - JM0043049) over the fighting with the 2” exhaust clamp. (JM0037668) •... -
Page 12: Assembly For Aluminum Valve
Assembly for Aluminum Valve If you have a Black Intercomp Valve go to “Assembly For Black Intercomp Valve” on page 14. If you have an Aluminum Valve, continue with the following instructions: STEP EIGHT - All models • Mount the flow control valve (JM0026104) using the flow control mounting bracket (LC290/LC390/SpeedTender Pro c4·50-JM0043097, LC535-JM0025400). - Page 13 STEP TEN - All models • Route the talc motor hydraulic hoses (JM0042861) through the conduits on the trailer as shown below. Tighten the hoses to the flow control valve and hydraulic talc motor. Route hoses through conduit on bottom side of shell weldment.
-
Page 14: Assembly For Black Intercomp Valve
Assembly For Black Intercomp Valve The black intercomp valve bank is shown on the left. Black Intercomp Valve Bank STEP NINE - All models • Remove the two 90° hydraulic fittings on the right side shown on the left. STEP TEN - All models •... -
Page 15: Hydraulic Schematic And Repair Parts For Black Intercomp Valve With Talc
Hydraulic Schematic and Repair Parts for Black Intercomp Valve with Talc 13 14 Description Part No. 3/8” Male JIC x 3/8” Male ORB; Extra Long 90 Degree Elbow (6801-LL-06-06) JM0039050 3/8” Male JIC x 3/8” Male ORB; 90 Degree Elbow JM0026121 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491... -
Page 16: Hydraulic Schematic And Repair Parts For Aluminum Valve Bank With Talc
Hydraulic Schematic and Repair Parts for Aluminum Valve Bank with Talc Hydraulic Motor Aluminum Valve Bank Conveyor Return Hose Flow Control To Conveyor Return Hose Description #6 male JIC X #6 male o-ring – Extra Long 90 degree elbow JM0039050 #6 male JIC X #6 male o-ring –... -
Page 17: Talc Parts For Lc290, Lc390 Speedtenders
18 290 Flex Auger Heat Bent PVC Pipe (45’) JM0042809 18 390 Flex Auger Heat Bent PVC Pipe JM0042810 19 Hydraulic Talc Flow Control Mounting Bracket JM0043097 20 Talc Rotation Bracket Weldment (Electric & Hydraulic Motor) JM0038395 21 1/2”-13 Gr5 Z Hex Nut JM0002124 22 1/2”-13 x 1”... -
Page 18: Talc Parts For Speedtender Pro C450
16 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181 17 Weed Whip Cord 18” - Professional Extreme - 5/32” JM0038500 18 Hydraulic Talc Spout Door Bracket JM0042542 19 535/c450 Flex Auger Heat Bent PVC Pipe... -
Page 19: Talc Parts For Lc535 Speedtender
Talc Parts for LC535 SpeedTender Description T-Handle Non-Locking Chrome JM0001911 17 Deg. Talc Box Door JM0037237 1/2" x 3/8" LG Shoulder Bolt JM0009998 3/8"-16 Gr5 Z SF Hex Nut JM0002152 3/8 USS Flat Washer JM0003061 2" Exhaust Clamp JM0037668 3/8-16 x 1" Gr5 Z SF Hex Bolt JM0002092 Large Talc Box Screen JM0037456...
