Test Instruction, Mechanical
Applicable for Z200, Z208
Contents
1
2
3
4
2/00021-1/FEA 209 544/8381A
Sony Ericsson Mobile Communications AB
Abstract............................................................................................................................2
Test Procedure ................................................................................................................2
Test flow...........................................................................................................................2
3.1
Software Update ................................................................................................2
3.1.1
Verify Software Version....................................................................................2
3.1.2
Update Software Version ..................................................................................2
3.2
Service Tests......................................................................................................3
3.2.1
Display Test.......................................................................................................3
3.2.2
LED/Illumination Test.......................................................................................3
3.2.3
Keyboard Test ...................................................................................................3
3.2.4
Buzzer Test........................................................................................................3
3.2.5
Earphone Test....................................................................................................4
3.2.6
Microphone Test................................................................................................4
3.2.7
Vibrator Test......................................................................................................4
3.2.8
Real Time Clock Test........................................................................................4
3.2.9
Flip Counter Test...............................................................................................4
3.2.10
Total Call Time Test..........................................................................................5
3.3
Manual Tests .....................................................................................................5
3.3.1
"On The Air Call" to the mobile .......................................................................5
3.3.2
System Connector Test......................................................................................5
Revision History ..............................................................................................................6
Test Instruction, Mechanical
Approved according to 000 21-LXE 107 42/1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony Ericsson Z200

  • Page 1 Test Instruction, Mechanical Test Instruction, Mechanical Applicable for Z200, Z208 Contents Abstract..........................2 Test Procedure ........................2 Test flow...........................2 Software Update ....................2 3.1.1 Verify Software Version..................2 3.1.2 Update Software Version ..................2 Service Tests......................3 3.2.1 Display Test.......................3 3.2.2 LED/Illumination Test..................3 3.2.3 Keyboard Test ....................3 3.2.4...
  • Page 2 1. Make assure that the phone’s battery is fully charged or use a Dummy battery and a power supply. Connect correct flash cable and interface according to the Installation instruction. 2. Connect to the Emma II server, choose application “GSM” and follow the instructions. 2/00021-1/FEA 209 544/8381A 2(6)  Sony Ericsson Mobile Communications AB...
  • Page 3 2. Adjust the volume with the joystick, by moving the navigation key to the left or right to increase or decrease the volume. 3. Press the “Ok” key to return to the service tests menu. 2/00021-1/FEA 209 544/8381A 3(6)  Sony Ericsson Mobile Communications AB...
  • Page 4 2. Number of flips will be displayed, the amount should increase every time the phone is closed and opened. 3. Press the “YES” or “NO” key to return to the service tests menu. 2/00021-1/FEA 209 544/8381A 4(6)  Sony Ericsson Mobile Communications AB...
  • Page 5 3. Connect the charger to the system connector and see if the phone starts to charge and if the charging is indicated in the display. 2/00021-1/FEA 209 544/8381A 5(6)  Sony Ericsson Mobile Communications AB...
  • Page 6 Test Instruction, Mechancial 4 Revision History Rev. Date Changes / Comments 2004-09-07 Initial release 2/00021-1/FEA 209 544/8381A 6(6)  Sony Ericsson Mobile Communications AB...
