Overview

System Specifications

Processor
■ SKU1: 8th Gen Intel
■ SKU2: 8th Gen Intel
15W
Memory
■ 2 x 260-pin SO-DIMM slots
■ Support the maximum of 32GB
■ SKU1: Dual-channel for DDR4 2133 MHz
■ SKU2: Dual-channel for DDR4 2400 MHz
Network
■ 1 x Intel I219LM GbE LAN PHY
®
■ 1 x Intel I210-AT GbE LAN
®
Storage
■ 1 x SATA 6 Gb/s, 2.5" HDD/SSD
■ 1 x mSATA slot (shared with Mini PCIe)
Expansion Slot
■ 1 x Half/Full-size Mini PCIe slot (w/ mSATA)
■ 1 x Half/Full-size Mini PCIe slot (w/ Nano-SIM holder)
■ SKU1
» 1 x M.2 E Key 2230 slot (2 x PCIe x1, USB 2.0)
» 1 x M.2 M Key 2242 slot (PCIe x4)
■ SKU2
» 1 x M.2 E Key 2230 slot (2 x PCIe x1, USB 2.0)
» 1 x M.2 M Key 2242 slot (PCIe x4, SATA)
Important
•
MS-9B05 only supports installing ONE WiFi / BT module. Please install
your WiFi / BT module to Mini PCIe slot1, Mini PCIe slot2 or M.2 E Key slot.
Audio
■ Realtek ALC887-VD2-CG HDA Codec
®
■ Compliant with Azalia 1.0 specs
1-6
Mobile Whiskey Lake-U Celeron
®
Mobile Whiskey Lake-U Core™ i5 Processor, QC,
®
Processor, DC, 15W
®
