Base introduction

M10 base is made of integrated design, and the body is clean and less port.
USB port:
Spare interface, SIMAGIC test interface
Used for product inspection, after-sales
inspection, etc.
USB-B port：
Use the factory
equipped USB-B
data cable to
connect to the PC.
Reset hole：
The M10 has a memory protection function. If
the user encounters problems with the
simulator system such as failure and no angle
limit state in use, he can use a pin or similar
object to reset the wheelbase.
Host vent:
Used for heat dissipation
during base operation,
Do not block.
USB Can Bus port.Can
be used to connect
Simagic peripheral
converter box or future
Simagic accesories
