Interface introduction

Mechanical setting interface, specific parameter adjustment page, where users can set and save
parameters of different scenes
Mechanical force：To enrich the handle of the game, which works while whether the game is
played or not.
TotalForce To adjust the output range of the Force engine. The positive or negative signs represent the
direction of the Force.
OverallFilter To adjust the smoothness of the output of force engine. The higher the value, the smoother
the output, the lower the resonance frequency, and the less the details.
WheelSpeed To adjust the highest speed of the wheel. The value on screen represents the highest speed.
SIMAGIC algorithm does not intervene if the speed is below this value;
Other wise the algorithm will limit the speed to set value.
WheelSpring To adjust the central spring of the wheel. The larger the offset from the center, the
greater the spring.
WheelDamper To adjust the mechanical damper of the wheel. The damper force hinders the wheel
rotation. Damper force= wheel speed * mechanical damper coefficient.
WheeFriction To adjust the mechanical friction of the wheel. The direction of friction is opposite to that of
wheel rotation. The value of friction can be adjusted by friction coefficient.
ConstantForce Represents steering power in most games.
PeriodForce In most games, it represents the intensity of game road, collision and other details.
