Aiphone MK-2DA Specifications

MK-2DA
2-Call Video Door Station
DESCRIPTION:
The MK-2DA is a 2-call video door station, used with
the MK-1MD/A room stations for audio and video
door answering. A perfect solution for a common
entry into two businesses, two residences, or one of
each.
A directory next to each call button identifies the
business or resident. The called location will hear a
4-stroke chime and see the image of the caller on
the monitor. The call is answered by picking up the
handset, while the visitor speaks hands free. The
door release button on the room station activates an
electric strike, allowing entry for the visitor.
The MK-2DA surface mounts to a wall, and is
compact in size. The built-in CCD camera provides
a wide angle view of the entry area, 95 degrees
horizontally and 70 degrees vertically.
Each business or residence can have one or two
monitors, or one monitor and one audio-only room
station, both able to answer a call from the door station.
COMPATIBLE COMPONENTS:
• MK-1MD/A Monitor/handset room station
• MK-1SD/B Audio handset (secondary to MK-1MD/A)
• PS-18YC/A power supply (1 per MK-1MD/A)

SPECIFICATIONS

Directories
FEATURES:
• Streamline surface mount design
• Selectively call two locations with individual
call buttons
• Directory by each button identifies tenant
• Each tenant can have two monitors, or
one monitor and one audio-only handset
• CCD camera with LED illuminators for low
light conditions
• Hands free communication
MOUNTING &
INSTALLATION:
CCD camera
Microphone
Call buttons
Speaker
