Instructions
1: key function
Batt. Type / Stop button: battery type and stop button, you can use this button to
switch in the main menu after receiving electricity, and you can press this button to
stop at any time while charging.
Dec. / Inc. <Status> button: Decrease and increase the button. Dec. is to decrease
and Inc. is increased when various values are set. Press these two buttons to browse
different battery information during charging.
Start / Enter button: Start and OK buttons;
Three: Lithium battery charge and discharge
1,) charging
After booting, the main menu is displayed:
PROGRAM SELECT
Lithium BATT
Press Start/Enter button to confirm
screen display
LiPo Balance CHG
6.0A AUTO (Because this charger balance mode automatically detects the number of
battery cells, it does not need to select the number of battery cells)
This is a lithium battery charge, for balanced charging, it is recommended to
continue. (For lithium batteries with balanced terminals)
Press the Start / Enter button again. The LIPO character will flash. Press DEC/INC to
select the type of battery (LiPo LiHv LiIo LiFe)
Press the Start / Enter button 6.0 when the battery type is selected. Flashing at this
time Press DEC / INC to select the charging current (it is recommended to select the
current according to the size of the battery) Note: Lithium polymer battery can not
exceed 1c, that is, 4400mah battery The maximum use of 4.4a, 2200mah battery
with a maximum of 2.2a, and so on; it is recommended to use a conservative point
0.5c, that is, 4400mah battery with 2.2a, and so on
Long press Start / Enter, the following screen appears:
Battery Check
Wait...
If the connection is correct, then:
Advertisement
Table of Contents
Related Manuals for HTRC C240 DUO
Summary of Contents for HTRC C240 DUO
- Page 1 Instructions 1: key function Batt. Type / Stop button: battery type and stop button, you can use this button to switch in the main menu after receiving electricity, and you can press this button to stop at any time while charging. Dec.
- Page 2 Up: R: *SER S: *SER (Indicating: R: *SER refers to the number of battery sections automatically detected by the charger. S: *SER is the number of battery sections you set. If the values are not equal, please do not start. Charge it so as not to damage the battery) Downstream: CANCEL (STOP) and CONFIRM (ENTER) switch back and forth Press Start / Enter to start charging, press Satt.
- Page 3 Nach dem Booten wird das Hauptmenü angezeigt: Programmauswahl Lithium BATT Drücken Sie die Start / Enter-Taste zur Bestätigung Bildschirmanzeige LiPo Balance CHG 6.0A AUTO (Da dieser Ladestandsmodus automatisch die Anzahl der Batteriezellen erkennt, muss nicht die Anzahl der Batteriezellen gewählt werden) Dies ist eine Ladung der Lithiumbatterie, für ausgeglichenes Laden wird empfohlen, fortzufahren.
- Page 4 Adaptateur Puissance de charge maximale: 80W Puissance de décharge maximale: 10W Valeur actuelle de charge: 0.1-6.0A Valeur du courant de décharge: 0.1-2.0A Courant de batterie unique: 400mah / cell Numéro de batterie Ni-MH / Ni-Cd: 1-15 cellule Série lithium-ion / polymère: 1-6 (Note: Batterie de soutien Li-Fe, c.-à-d.
- Page 5 batterie 4400mah avec 2.2a, et ainsi de suite Appuyez longuement sur Start / Enter, l'écran suivant apparaît: Vérification de la batterie Attendez... Si la connexion est correcte, alors: Up: R: * SER S: * SER (Indique: R: * SER correspond au nombre de sections de batterie détectées automatiquement par le chargeur S: * SER correspond au nombre de sections de batterie que vous avez définies.
- Page 6 Tre: carica e scarica della batteria al litio 1,) ricarica Dopo l'avvio, viene visualizzato il menu principale: SELEZIONE PROGRAMMA Litio BATT Premere il tasto Start / Enter per confermare schermo LiPo Balance CHG 6.0A AUTO (Poiché questa modalità di bilanciamento del caricatore rileva automaticamente il numero di celle della batteria, non è...
- Page 7 *. * A *. * V (* S) Premi Start / Enter, seleziona \ function, Il metodo di funzionamento è identico a quello di carica e può essere impostata la corrente di scarica e la tensione di fine scarica. La tensione viene aumentata o diminuita di un multiplo di 3 e la batteria al litio da 7,4 V è...
- Page 8 Si la conexión es correcta, entonces: Arriba: R: * SER S: * SER (que indica: R: * SER se refiere a la cantidad de secciones de batería detectadas automáticamente por el cargador. S: * SER es el número de secciones de batería que ha configurado. Si los valores no son Igual, no empieces, cárgalo para no dañar la batería.
