- Page 1 SLS-C Power Supply Unit with Built-in Power Stages Type MSX or ZMX SLS-C SUPM07 SUPM07 Extreme. Precision. Positioning. SLS-C SUPM12 SUPM12 Extreme. Precision. Positioning. Manual 1317-A001 EN Extreme. Precision. Positioning.
- Page 3 SLS-C 19“ Unit for Stepper Motor Controllers with built-in Power Stages and ZMX 02/2021 Manual MA 1317-A001 EN...
- Page 4 Questions about the use of the product described in the manual that you cannot find answered here, please contact your representative of Phytron (http://www.phytron.eu/) in your local agencies. The wiring diagram of the SLS-C is enclosed with the unit on delivery. MA 1317-A001 EN...
-
Page 5: Table Of Contents
Brief description of the SLS-C ..................8 2.1 MSX and ZMX Power Stages ..................9 2.2 SLS-C with Customised Unit Design ................9 Transport and Storage Information ................10 Suitable Installation Location ..................11 Mounting Information ....................12 Protective Measure for Power Supply Units with Power Stages up to 70 V ..... -
Page 6: Legal Information
SLS-C Manual 1 Legal Information This manual: Read this manual very carefully before mounting, installing and operating the device and if necessary further manuals related to this product. - Please pay special attention to instructions that are marked as follows: DANGER –... - Page 7 Observe the following safety instructions! Qualified personnel WARNING – Serious injury possible! Serious personal injury or serious damage to the machine and drives could be caused by insufficiently trained personnel! Without proper training and qualifications, damage to devices and injury might...
- Page 8 EMC Directives are conformed with. WARNING – Serious injury from electric shock! If the SLS-C is not operated with SELV/PELV voltages, the risk of dangerous voltages may be on the device. Touching these components carrying high voltages can cause serious injury or death from electric shock: - Always observe the safety concept SELV / PELV to ensure safe isolation and separation of low voltage supplies from the mains.
- Page 9 CAUTION – Possible injury! The SLS-C may weigh up to 30 kg (66 lb), depending on the expansion stage. Foot injuries can occur from dropping the unit. - Make sure that the SLS-C is securely held at all times - Wear safety shoes during transport and handling.
-
Page 10: Brief Description Of The Sls-C
SLS-C Manual 2 Brief description of the SLS-C SLS-C MSX /ZMX is a series of power plug-in units for stepper motor controllers. The unit is constructed in 19" technology: width 19" (482.6 mm), height 3 U (132.5 mm), depth 420 mm ... -
Page 11: Msx
- Please check the adjusted current for the stepper motor by means of the motor’s type plate See the power stage manual for detailed information SLS-C with Customised Unit Design Further technical information The customer-specific pin assignment of the connector plugs can be found in the wiring diagram supplied. -
Page 12: Transport And Storage Information
CAUTION – Possible injury! The SLS-C may weigh up to 30 kg (66 lb), depending on the expansion stage. Foot injuries can occur from dropping the unit - Make sure that the SLS-C is securely held at all times - Wear safety shoes during transport and handling. -
Page 13: Suitable Installation Location
2000 m max. above sea level CAUTION – Possible injury! The SLS-C may weigh up to 30 kg (66 lb), depending on the expansion stage. Foot injuries can occur from dropping the unit. - Make sure that the SLS-C is securely held at all times - Wear safety shoes during transport and handling. -
Page 14: Mounting Information
- Mounting rails must be fitted to the 19” device. - Insert the SLS-C from the front into the rack and screw it on the left and right side of the designated holes with the rack. - Tighten the screws well. -
Page 15: Protective Measure For Power Supply Units With Power Stages Up To 70 Vdc
Power Stages up to 70 V SLS-C with power stages up to 70 VDC must be operated by the protective measure PELV acc. to VDE 0100. The unit and motor housing have to be grounded. The ‘0 V’ in the unit is grounded. -
Page 16: Protective Measure For Power Supply Units With Power Stages Up To 120 Vdc
Protective Measure for Power Supply Units with Power Stages up to 120 V The power supply SLS-C units with power stages over 70 V must be operated according to VDE 0100 part 200 with protection by automatic disconnection. Therefore, the motor, power stage, `0 V` and each equipment have to be grounded: CAUTION –... -
Page 17: Cabling Design Requirements
8 Cabling Design Requirements Which devices? SLS-C power supply units with built-in power stages type Which cables? Mains, I/O, logic control and motor cables The secondary motor circuits (motor current circuit, I/O and logic What is to be circuit) are not insulated by means of a protective separation as observed? defined by the EN 50178 European Standard. -
Page 18: Emc Requirements
SLS-C Manual 9 EMC Requirements CAUTION – Possible damages! Please consider the following references for EMC reliability Only use shielded cables - The cables should not be interrupted by additional connectors or screw terminals from the unit to the motor in order not to deteriorate the... - Page 19 Connection of the cable shield to the motor acc. to EMC rules MA 1317-A001 EN...
-
Page 20: Mains Connection
SLS-C Manual 10 Mains Connection The SLS-C is supplied with 115 to 230 V mains voltage via the NETM03 module. Power entry module with non-heating socket (3 x 0.75 mm 2-pole mains switch, nominal current up to 10 A, acc. to IEC 60320 C14... - Page 21 WARNING – Serious injury possible! To avoid personal injury please consider the following items: - The operating voltage indicated on the type plate should match the local supply voltage. - Connect the cable only to the socket with a protective earth contact.
-
Page 22: Control Pulses Connector - Standard
Pin assignment of the 9-pin D-SUB control pulses connector (male) – MSX+ standard Pin assignment of the 9-pin D-SUB control pulses connector (male) – ZMX+ standard The control pulses connectors of the control unit and the SLS-C power stages unit are connected by means of a shielded cable. -
Page 23: Motor Connector And Connection - Standard
12 Motor Connector and Connection - Standard Phytron uses the 6-pin Harting connector as standard for connecting the motor. Further technical information The customer-specific pin assignment of the motor connector can be found in the wiring diagram supplied. 6-pin Harting connector acc. To DIN 43652 Stepper motor wiring diagram acc. - Page 24 SLS-C Manual WARNING – Serious injury from electric shock! During electrical installation cables, connectors, etc. can be live. Connection of the connector to the motor cable Skin the cable as short as possible Insulate the shielding with shrinkable tubing - Do not plug or unplug the connectors while powered.
-
Page 25: Servicebus Operation
RS485 interface connector, 9-pin D-SUB (female), standard 13.2 The connection of the SLS-CZMX+ acc. to RS 485 (4 wire operation): PC connection -> SLS-C via USB/RS 485 converter PC connection -> SLS-C via RS 422/RS 485 interface MA 1317-A001 EN... - Page 26 SLS-C Manual Addressing of the power stages is done in ascending order from right to left on delivery. Each address should only be used once (0...F). Power stage Setting of the address by ZMX+ the rotary switch on the power stage front panel...
-
Page 27: Esd Protection Measures
15 Warranty The SLS-C unit is subject to legal warranty. Phytron will repair or exchange devices which show a failure due to defects in material or caused by the production process. This warranty does not include damage caused by the customer, for example, not intended use, unauthorised modifications, incorrect handling or wiring. -
Page 28: Index
SLS-C Manual 16 Index Power stages 9 Protective measure 13 Cable 16 Control pulses connector 20 Copyright 2 Rated voltage 15 Rear side 8 Rotary switch 24 EMC 16 RS 485 23 Front side 8 Safety instructions 6 SELV/PELV 6, 13... - Page 29 Phytron GmbH Industriestraße 12 – 82194 Gröbenzell T+49-8142-503-0 F +49-8142-503-190 www.phytron.eu...
