Agnpro X-15AV Specifications

PROFESSIONAL DISPLAY SOLUTIONS
MULTI-SOURCE FLAT PANEL CCTV MONITORS
XP SERIES |
FOR HIGH-END RESIDENTIAL, CORPORATE
www.agnpro.com
AND RETAIL INSTALLATIONS
3 year warranty
FEATURES
• 19" TFT LCD
• Composite / VGA / DVI Inputs
• Resolution: SXGA 1280 x 1024
• Contrast Ratio: 700:1 (typical)
• BNC with Loop Through
• Protective Optical Glass Filter
• Rugged Aluminum Alloy Construction
• Security Industry Compatibility
• EVS Input Technology
• Wall or Arm Mount Available
About the NeoV Optical Filter:
NeoV
The NeoV Optical Filter is
OPTICAL FILTER
a specially formulated,
hardened optical glass (6H Moh's
Rating) that is built on top of the
internal LCD panel to dramatically
enhance image quality and pro-
NeoV Optical Filter
tect the screen from damage.
XP19AV
About EVS Input Technology:
EVS
Enhanced Video Signal (EVS) Input monitors provide the
highest compatibility with CCTV equipment and enhanced
video clarity. Unlike many flat panel monitors designed for the PC
industry, EVS enabled monitors will not experience dropped signals as
a result of video signal hunting. Dropped signals and poor composite
video quality have made most flat panel monitors (designed for the PC
industry) difficult and undesirable to use with multiplexers and digital
recorders. AGNPRO monitors are designed for video surveillance
applications and are the most compatible in the industry.
SPECIFICATION
Available in 17", 19" TFT LCD. 15" and 20.1" available in X-Series*
Panel Panel Type
Max. Resolution
Pixel Pitch
Contrast Ratio
Brightness
Display Colors
Response Time
Wide Viewing Angle
Inputs Input Type
Video Standard
Connectors Composite
S-Video
VGA
Digital (DVI-D)
EVS Input Technology Enabled
Protective Glass NeoV Optical Filter
Special Features
Tilt Angle
Mounting Vesa FPMPMI
Regulation Approval Safety & EMI
Power Power Source
Consumption
Dimensions Net (W X H X D)
Packing (W X H X D)
Weight Net Weight
Gross Weight
All specifications are subject to change without prior notice.
* X-15AV, X-20AV
19" TFT LCD
SXGA 1280 x 1024
0.294mm
700:1
300cd/m 2
16.7M
25ms (Total)
170°/170°
Composite / VGA / DVI
NTSC/PAL/SECAM
BNC In / Out Loop-through
N/A
15-Pin D-Sub
29-Pin DVI
Yes
6H (Moh's Rating)
Aluminum Alloy Construction,
Kensington Lock
0°-15°
Yes (100mm)
FCC, UL/CUL, TUV / BAURT, CE, TCO
'95, BSMI, VCCI, CB, ISO 13406-2
100 - 245V, 50 - 60Hz
<48W (On)
<5W (Off)
17.5" x 16.5" x 6.9"
21.2" x 20.7" x 9"
17.4 lb (7.9Kg)
23.57 lb (10.7Kg)
PROFESSIONAL DISPLAY SOLUTIONS
AGN Professional (AGNPRO)
156 Fifth Avenue Suite 434
New York, NY 10010 USA
Tel: 1-212-647-9080
Fax: 1-212-647-9084
sales@agnpro.com
www.agnpro.com
SS-XP19AV-V3-0306
