balcom TLT 06 Operating Instructions Manual page 3

PROGRAMMING
For programming and control function a standard
telephone with the usual 12 buttons
und ( MFV ) dialing is necessary.
Access to the programming mode is only possible
for authorized persons by use of a PIN -Number
(Personal Identification Number).
There are 6 memories available each of which can
memorize upto 32 digits( N1, N2...) or special signs.
The memories are assigned to the appropriate
buttons ( see connection diagramm ).
As soon as a speech connection to the TLT 06 is
built up, the electronic power switch can be
00
activated by dialing ( ) or a PIN
For safety against unauthorized intervention, the
entrance to the programming mode is protected by
a PIN-code.
Special signs, depending on the operation can also
be memorized together with the telephone number.
example getting an external line
with " Flash "
1 # 0
*
1 0
with " " 0 *
The memorized telephone numbers and settings
are saved in a non volatile memory. This prevents
the loss of data by a voltage failure.
The behavior of the TLT 06 after putting the telephone on-hook can vary and is dependent on the used PABX telephone system. If the period of the
reciept tones seems to be too long, the following short-cut can help. Instead of just putting the telephone on-hook press the star (*) button of the
keypad first and then put the telephone on-hook. A reciept tone sounds as a hand shake of this and approx. 5 secs. after this 4 beep tones, then the
TLT 06 goe's automatically offline. Normally this procedur is not necessary and the TLT 06 beeps about 3-4 times during busytone detection and
then goe's offline without any further action.
TONE's and SIGNALIZING :
Occupied ( PABX ):
Extension occupied:
Hand-shake tone:
Error tone:
*
( 0...9, , # )
1
2
3
-Code.
9
:
. . .
N1 N2
# 1
*
. . .
# 1 N1 N2
*
.... Is dependent
.... Extension occupied / busy-tone detection
.... Hand-shake tone and during Programming.
.... Signalizes a Programm error, wrong PIN-code or after 5 sec. by the use of the Star
( * ) button for fast Speech disconnection.
Entrance to Programming mode
Lift the Handset of any telephone on the PABX.
Dial the Internal extension number of the TLT 06
and wait until aconnection is built up.
Dial (*) Pin-Code (*)
P1 P2 P3 P4
* *
Default setting ex works is:
Memorizing telephone number's
. . . Programm memory No. 1 with a telephone number
N1 N2
* *
. . .
Programm memory No. 2 with a telephone number
N1 N2
* *
. . .
N1 N2 Programm memory No. 3 with a telephone number
* *
etc. up to memory No. 6 ( when used )
Electrical Door-opener
with
8 0
* *
1
8
* *
Changing the PIN-Code (
Enter new PIN-Code.
P1 P2 P3 P4
* *
P1 - P4 are four digits from 1 - 9 via the keypad
Special function keys (
Will be dialled:
# #
#
*
Flash (R)
# 0
# 1 Break
Finalize Programming
#
Replace the handset ( on-hook )
on the used PABX telephone system.
Programming
2 2 2 2
0 0
Default setting ex works
Or
P1 P2 P3 P4
An individual ( 4 digit ) PIN-Code
Optional
Optional
#
*
)
)
