INSTALLATION GUIDE
THD PRODUCT NAME: Hampton Bay Courtland Shaker Cabinetry
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this cabinetry product. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Courtland Shaker Cabinetry and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY Courtland Shaker Cabinetry

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this cabinetry product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Installation ..............9 Safety Information ............2 STEP 1: Outline on Floor and Walls ......9 Utilities Safety .............. 2 STEP 2: Locate and Mark Wall Studs ......9 INSTALLATION Safety ..........2 STEP 3: Mounting Under a Soffit or Low Ceiling ..
  • Page 3: Warranty

    Warranty LIMITED LIFETIME WARRANTY WHAT IS COVERED The manufacturer (“Manufacturer”) warrants its parts and products to be free of substantial defects in materials and workmanship from the original date of purchase under normal home use. This warranty is offered only to the original consumer purchaser and may not be transferred. WHAT IS NOT COVERED This warranty does not cover any problems or damages which result from improper transportation, improper installation, mishandling, misuse, abuse, neglect, abnormal use, commercial use, improper maintenance, non-authorized repairs, accidents, or acts of God, such as hurricanes, fire, earthquakes or...
  • Page 4: Pre-Installation

    CHECK YOUR ORDER Make sure the product label on each carton matches the product numbers on your order and project plan. Contact Hampton Bay Customer Service if there are any damaged, missing, or incorrect cabinets. Do not install if damaged or parts are missing.
  • Page 5: Dry Fit

    Pre-installation (continued) DRY FIT: Perform the dry fit of cabinets after you have determined the high point of the floor (see Installation Requirements). With the cabinets in place, you can see how important the Base Cabinet Top Level Line is. When installed, all base cabinet tops should match this line exactly. IMPORTANT: If any cabinet is above the Base Cabinet Top Level Line, then the high point is not correct.
  • Page 6: Installing Wall Cabinets First

    Pre-installation (continued) INSTALLING WALL CABINETS Whether you start at a corner or an end, the general approach with wall cabinet installation is to: 1. Mark on the back of the cabinet where the cabinet will line up with the wall studs (see further instructions page 13). 2.
  • Page 7: Door, Drawer, & Shelf Removal

    Installation Requirements (continued) DOOR, DRAWER, & SHELF REMOVAL Remove doors, drawers, and roll-out trays so they aren’t in the way during Remove Screw installation. Removal also makes the cabinets lighter to move. Label each piece Door Hinge with masking tape so you know where to reinstall each piece. Store them face to face to avoid damage.
  • Page 8: High Point Level Line

    Installation Requirements (continued) HIGH POINT LEVEL LINE Measure out 20-7/8" from the wall (where the base cabinets toekick line will be) and snap a line on the floor parallel to the wall. To find the highest point on the floor, place one end of a straight 2 x 4 at the end of the cabinet run. Place a carpenter’s level on top and check the bubble.
  • Page 9: Installation

    Installation OUTLINE ON FLOOR AND WALLS LOCATE AND MARK WALL STUDS o Measure 19-1/2" up from the Base Cabinet Top Level Line and snap o Typical wall construction places wall studs on 16" centers. This a level line on the wall. This is the Bottom of Wall Cabinet Level Line. means that every 16"...
  • Page 10: Step 3: Mounting Under A Soffit Or Low Ceiling

    using the same process as done for finding the high spot on the floor. Snap a level line. This will be the Wall Cabinet Top Level Line. Installation Measure down 30", 36" or 42" (the height of your wall cabinets) to confirm the distance between the Wall Cabinet Bottom Level Line and the Base Cabinet Top Level Line.
  • Page 11: Step 6: Attachment Minimum Requirements

    Installation FRAME-TO-FRAME ATTACHMENT ATTACHMENT MINIMUM REQUIREMENTS o All cabinet frames must be fastened to adjacent cabinet frame, o On a 1/8" drill bit, set tape or drill depth gauge at 2-1/2". fillers, side wall, or ceiling. evel Line o Before drilling face frames, recheck for level and that alignment s).
  • Page 12: Step 7: Attachment To Wall

    Installation ATTACHMENT TO WALL ATTACHMENT TO WALL (CONTINUED) o On base cabinets, don’t attach cabinets to the wall until all cabinet INSTALLER NOTE: For wall cabinets, drill 2" down from the top and Face Frames are fastened together. Re-check each cabinet for level 2"...
  • Page 13: Step 8: Attachment To Ceiling

    Installation ATTACHMENT TO CEILING COUNTERTOP BRACES o When installing cabinets or fillers that leave a void between the o Follow the Attachment to Wall requirement to attach the face frame wall and cabinet/filler, you must install a 1 x 3 Brace to support the to the ceiling joists;...
  • Page 14: Step 10: Deep Wall Cabinet

    Installation DEEP WALL CABINET DOUBLE DOOR CABINET SHELVES o Remove drawer(s) and install shelf (shipped separately in carton) WARNING: DO NOT install a Deep Wall Cabinet through open top of cabinet. Shelf cannot be installed through the independently. Failure to follow this warning may result door opening.
  • Page 15: Step 12: Base Blind Corner Cabinets

    Installation BASE BLIND CORNER CABINETS BASE BLIND CORNER CABINETS (CONTINUED) o During the “dry fit” step, it is a good time to check the blind corner o Position the hidden end of the Base Blind Corner cabinet at the cabinet spacing from the corner wall. proper spacing from the wall.
  • Page 16: Step 13: Base Corner Cabinets

    Installation BASE CORNER CABINETS WALL FILLER; BASE, WALL o The approach to install Base Corner cabinets is to attach the o Wall Fillers are available to fill gaps between the end of a row of adjacent cabinets on each side and install the group of cabinets as a cabinets and a 90°...
  • Page 17: Step 15: Fillers For Various Depth

    Installation WALL FILLER; BASE, WALL (CONTINUED) FILLERS FOR VARIOUS DEPTH o When installing cabinets next to each other that are different depths o Place, shim, level, and install the final cabinet. With the final cabinet (i.e. 12” deep next to 24” deep), a Filler or Full Height Panel will be in place, measure the gap between the wall and the top of the required to maintain the spacing of the cabinets.
  • Page 18: Step 16: Tall End Filler & 24" Deep Wall Cabinet Installation

    Installation TALL END FILLER & 24" DEEP WALL CABINET TOEKICK PLATFORM WITH 96" TALL CABINETS INSTALLATION o The Tall End Filler conceals the side of a refrigerator and supports o The Toekick Platform is shipped unattached on 96” Tall cabinets. If a 24"...
  • Page 19: Step 18: Oven Cut-Out And Oven Support Platform

    Installation OVEN CUT-OUT AND OVEN SUPPORT PLATFORM OVEN CUT-OUT AND OVEN SUPPORT PLATFORM (CONTINUED) o Determine oven opening size (rough-in dimensions) by referring to the oven manufacturer’s specifications; or measure your oven. Diagram cutout and trim recommendations Position the oven so a minimum of 1-1/2" of frame cross rail is left Double Oven Assembled Cabinet above and below the oven to retain rigidity of the cabinet frame.
  • Page 20: Step 19: Bookcase

    Installation CONVERSION OF VANITY DRAWERS TO FALSE BOOKCASE FRONT o Installation of a bookcase by itself is NOT recommended unless o The drawers can be changed to a false front if twin or off-center sink additional support such as attachment to a soffit or supported by a bowl locations are required.
  • Page 21: Step 22: Wall Microwave Shelf

    Installation WALL MICROWAVE SHELF TOEKICK COVERS o Transfer measurements for the location of the electrical outlet onto o Measure the length of the toekick area and cut the Toekick Cover to the back of the Wall Microwave Shelf. Cut the hole in the cabinet that length.
  • Page 22: Step 25: 6-Way Hinge Adjustments

    Installation 6-WAY HINGE ADJUSTMENTS o A. Up and down adjustment ….….…. +/- 2.0mm. Loosen Screw A, align door, tighten Screw A. DO NOT overtighten Screw A. o B. Left or Right adjustment ………….. +/- 1.5mm. Turn Screw B clockwise or counterclockwise. o C.
