Sanden Vendo Vue SXY 30 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

®
SXY
TABLE OF CONTENTS
i
Part #1167879
07/2008

Advertisement

Table of Contents
loading

Related Manuals for Sanden Vendo Vue SXY 30

Summary of Contents for Sanden Vendo Vue SXY 30

  • Page 1 ® TABLE OF CONTENTS Part #1167879 07/2008...

  • Page 2: Table Of Contents

    Table of Contents Safety S-1 - S-17 Commitment to Safety...................S-2 Vendor Installation..................S-3 Electrical Hazards ..................S-7 Mechanical Hazards..................S-10 Refrigeration Hazards ...................S-11 Temperature Hazards..................S-11 Substitutions and Modifications..............S-12 Consumer Safety Warning ................S-14 Parts, Sales, and Service Centers ..............S-15 Parts, Sales, and Service Centers for Latin America ........S-16 General Information G-1 - G-8 General Information ..................G-2...
  • Page 3 Custom Message ..................P-26 Return ......................P-27 Wiring Diagram .....................P-28 Custom Space to Sales Diagram ..............P-30 Cabinet Parts C-1 - C-11 Cabinet Assembly ..................C-2 Refrigeration Assembly .................C-4 Power Distribution Assembly.................C-5 Harness Quick Guide ..................C-7 Shelves & Trays Parts ST-1 - ST-5 Shelves & Trays Assembly ................ST-2 Tray Assembly ....................ST-3 Door Parts D-1 - D-29...

  • Page 4: Safety

    ® SAFETY SECTION Part #1167879 07/2008...

  • Page 5: Commitment To Safety

    A COMMITMENT TO SAFETY SandenVendo America is committed to safety in every aspect of our product design. SandenVendo America is committed to alerting every user to the possible dangers involved in improper handling or maintenance of our equipment. The servicing of any electrical or mechanical device involves potential hazards, both to those servicing the equipment and to users of the equipment.

  • Page 6: Vendor Installation

    SECTION I: VENDOR INSTALLATION Vendors are large, bulky machines of significant size and weight. Improper handling can result in injury. When moving a vendor, carefully plan the route to be taken and the people and equipment required to accomplish the task safely. Remove all tape, shipping sealant, and Styrofoam from the vendor.
  • Page 7 FIGURE 1 Part #1167879 07/2008...
  • Page 8 SECTION I: VENDOR INSTALLATION (CONTINUED) For Type 1 and Type 2 outlets, test for Grounding and Polarization as follows: With a test device (volt meter or test light), connect one probe to the receptacle’s neutral contact and the other to the live contact. The test device should show a reaction.
  • Page 9 Door Support (Figure 2) The door support is to ensure that the outer door closes squarely to the cabinet. FIGURE 2 NOTE: Refer to the appropriate parts and service manual for detailed instructions, operating principles, and recommended maintenance intervals and procedures.

  • Page 10: Electrical Hazards

    SECTION II: ELECTRICAL HAZARDS GENERAL SandenVendo America, Inc. vending machines are provided with the appropriate power supply setting for your area. Some models are equipped with step-down transformers, as required. This enables the vending machine to operate on different main voltages. Refer to Section I.
  • Page 11 SECTION II: ELECTRICAL HAZARDS (CONTINUED) Servicing with “Power Off” For maximum safety, unplug the service cord from the wall outlet before opening the vendor door. This will remove power from the equipment and avoid electrical and mechanical hazards. Service personnel should remain aware of possible hazards from hot components even though electrical power is off.
  • Page 12 0.8 AMP FUSE 3.15 AMP FUSE FIGURE 3 Part #1167879 07/2008...

  • Page 13: Mechanical Hazards

    SECTION III: MECHANICAL HAZARDS Servicing of Moving Parts and Assemblies When servicing assemblies involving moving parts, use extreme caution!! Keep fingers, hands, loose clothing, hair, tools, or any foreign material clear of entrapment. As noted before under the electrical hazards section, Power On servicing should only be performed by qualified personnel.

  • Page 14: Refrigeration Hazards

    SECTION IV: REFRIGERATION HAZARDS GENERAL Refrigeration systems involve both electrical power and mechanical action. These systems may present any of the potential dangers shown in the sections on electrical and mechanical hazards contained in this manual. See Sections II and III for further information.

  • Page 15: Substitutions And Modifications

    SECTION VI: SUBSTITUTIONS AND MODIFICATIONS GENERAL Unauthorized changes or the substitution of unauthorized parts can compromise the equipment designs. This can result in unsafe conditions for either the service personnel or the equipment users. Always refer to the appropriate parts and service manual for replacement parts and maintenance instructions.
  • Page 16 SECTION VI: SUBSTITUTIONS AND MODIFICATIONS (CONTINUED) WARNING THIS APPLIANCE MUST BE EARTHED. IMPORTANT! The wires in the main leads are colored in accordance with the following code: 110v/120v 220v/240v Green Green and Yellow ......Earth White Blue ........... Neutral Black Brown ..........

  • Page 17: Consumer Safety Warning

    SECTION VII: CONSUMER SAFETY WARNING WARNING VENDOR CAN BE OVERTURNED IF SUFFICIENT FORCE IS APPLIED AND MAY RESULT IN SERIOUS INJURY OR DEATH. GENERAL There have been incidents, including fatalities, when vending machines have been vandalized by being pulled over in an attempt to obtain free product or money. To warn of the danger involved in tipping, shaking, or rocking the vending machine, a decal has been designed to be affixed to vending machines.

  • Page 18: Parts, Sales, And Service Centers

    Fax: 61-2-9791-9029 New Zealand N.S.W. 2200 Australia Sanden International (Singapore) Pte., Ltd. Tel: 65-482-5500 Singapore, Hong Kong, Sanden House, 25, Ang Mo Kio St. 65 Fax: 65-482-1697 Singapore 569062 Indonesia, The Republic of Singapore Phillippines, India Tel: 886-2-570-6106 Taiwan Sanden International Taiwan Corp.
  • Page 19 PARTS, SALES, & SERVICE CENTERS OF THE SANDEN COMPANY FOR LATIN AMERICA AREA ADDRESS PHONE NUMBERS Mexico Vendo de Mexico Tel: (52) 427 2718096 Carreta Mexico - Tequisquiapan Km 3.2 Fax: (52) 427 2718077 San Juan del Rio, Queretaro C.P. 76800 Mexico IMI Cornelius de Mexico, S.A.
  • Page 20 NOTES Part #1167879 07/2008 S-17...

  • Page 29: Cleaning Information

    ® CLEANING INFORMATION SECTION CL-1 Part #1167879 07/2008...

  • Page 30: Care And Cleaning

    CARE AND CLEANING DO NOT USE WATER JET FOR CLEANING. AVOID USING WATER OR ANY OTHER LIQUIDS NEAR ELECTRONIC COMPONENTS GENERAL PROCEDURE (painted metal areas) Wash the vendor with soap and water. The exterior may be waxed with any good automobile wax.
  • Page 31 REFRIGERATION AREA The condenser and evaporator must be kept clean for efficient operation. Be sure all vanes and tubing are clean and clear of obstruction; this allows free passage of air. Clean with a brush, a vacuum cleaner or compressed air, using extreme caution not to bend the condenser fins.
  • Page 32 NOTES CL-4 Part #1167879 07/2008...

  • Page 33: Programming

    ® VEC 15.4 PROGRAMMING SECTION Part #1167879 08/2008...

  • Page 34: Vec 15 Programming Operation

    VEC 15 PROGRAMMING OPERATION NOTE: Some units may contain a European font display, in which case the “°” symbol will be replaced by the “ß” symbol. Example: 72°F will be 72 ß F. The VEC 15.1 Controller uses a 4-button programming system: Programming Buttons: # 1 –...

  • Page 35: Diagnostics

    Discount Counter** Free Counter** Space to Sales* Configuration* Door Closed Password* Set Language* Set Clock *** Lighting *** Refrigeration **** Sales Block 1-8 *** Discount *** Override ***** Custom Message* Return The options are in password protected mode. To access these features please scroll to Password, Press enter and press 2314.

  • Page 36: Tube Fill

    Tube Fill: The changer coin tubes can be filled via the external coin insert plate or the acceptor part of the changer. This mode enables the Control Board to keep an accurate count of the coins. 1. Press Button 2 to scroll until “Tube Fill” is displayed. 2.
  • Page 37 Drink Location for Test Vend: SXY30, 5 Shelves SXY30, 6 Shelves Test Mode Vending: (Only for machines with a lot code older than 08074T ) 1. Still in Test Mode, Press Button 2 to scroll until “Vending” is displayed. *2. Press Button 4 – Display will read ‘Close Door to Vend’. 3.
  • Page 38 Drink Location for Test Vend: SXY40, 5 Shelves SXY40, 6 Shelves Drink Location for Test Vend: SXY30, 5 Shelves SXY30, 6 Shelves Part #1167879 08/2008...
  • Page 39 Test Mode Vend Specific Column: 1. Still in Test Mode, Press Button 2 to scroll until “Vend Specific Column” is displayed. 2. Press Button 4 to Enter. 3. Close outer door. 4. Display will read ‘Test Vend Column No. #XX’. 5.
  • Page 40 4. Enter on Button 4 – ‘Testing in Progress’ – Hand should move to the Lock side of the door. 5. Exit on Button 1. 6. Advance on Button 2 – ‘Go Opposite of Home’. 7. Enter on Button 4 – ‘Testing in Progress’ – Hand should move to hinge side of the door.
  • Page 41 ALWAYS ENSURE THE CLAMP HAND HAS RETRACTED BEFORE CLOSING THE DOOR Note – When you are in any Test Motor operation where the ‘HAND’ is Extended be sure to EXIT MODE on Button 1 before closing the Door Test Mode Sensors Status: Note: If the sensors are being replaced, press ‘4’...

  • Page 42: Calibration

    4. To Exit, press and hold Button 1 for 5 seconds or until Display returns to ‘Test Mode Switches’ Test Mode Relays: This Mode allows you to test the following relays: 1. Compressor 2. Fluorescent Light 3. Heater 4. Fan 1.
  • Page 43 1. Press Button 2 to scroll until “Discover” is displayed. 2. Enter on Button 4 – ‘Discovery Level 0’ 3. Advance on Button 2 to desired level 4. Press Button 4 to save 5. If Level 1 or 2 is chosen, the display will read ‘Please close the door’ followed by ‘Press 1 –...

  • Page 44: Cash Data

    Calibration Test Vend-No pdt: Allows the vendor to do a self- test of all positions including running the Hopper Flap and Hopper Bucket. 1. Press Button 2 to scroll until “Password” is displayed. 2. Enter the password, 2582. 3. Press Button 4 to enter. 4.

  • Page 45: Set Price

    5. Press Button 1 to exit. Set Price: This Mode allows you the option to price each selection to the same vend price, or price each shelf, tray or column. (Refer to diagram on next page) To set all selections to a ‘single price’: 1.
  • Page 46 SXY40 Space to Sales - Plan-o-gram Coke and Coke Zero SXY30 Space to Sales - Plan-o-gram Coke and Coke Zero P-14 Part #1167879 08/2008...
  • Page 47 SXY40 Space to Sales - Plan-o-gram SXY30 Space to Sales - Plan-o-gram P-15 Part #1167879 08/2008...
  • Page 48 SXY40 Space to Sales - Plan-o-gram SXY30 Space to Sales - Plan-o-gram P-16 Part #1167879 08/2008...

  • Page 49: Discount Counter

    Space to Sales - Custom Clear: This allows the user to clear the individual buttons from any column on the vendor. 1. Enter on Button 4 - Display reads “Clear All? Yes-4 No-3”. Press 3 to clear individual selection or 4 to clear all locations. 2.

  • Page 50: Free Counter

    3. Advance on Button 2 to scroll through the various selections 4. Press Button 1 to exit 5. Advance on Button 2 – ‘Sales Data’ 6. Enter on Button 4 – ‘Sales Data Total’ will display as well as the number of discounted sales.
  • Page 51 Off – Credit established will remain until either a vend is made or the coin return is pressed. Force Vend: On - The consumer will not be able to deposit money, press the coin return and receive change without attempting a vend first. Off –...

  • Page 52: Door Closed Password

    Set # of Trays: Allows the operator to ‘choose’ the number of ‘Trays’ in the vendor. 1. Enter on Button 4 - ‘Set # of Trays 3, 4, or 5’ 2. Enter on Button 4 - ‘3, 4, or 5’ is flashing 3.

  • Page 53: Set Language

    1. Exit to Menu. Press Button 2 until “Door Closed Password” is displayed. digit flashing 2. Enter on Button 4 – current ‘Password’ will display with the 1 indicating that it is ready to be edited 3. Press Buttons 2 and 3 to change the digits. NOTE: Valid digits are 1 through 6. The Password 0000 will disable this feature.

  • Page 54: Lighting

    22. Advance on Button 2 to correct minutes 23. Press Button 4 to save setting – MM/DD/YYYY HH:MM will display 24. Press Button 1 to exit - Set Clock Lighting: ‘Timing Features’ in Configuration Mode must be turned ‘On’ to access this feature. You have the option to turn the lights or LED off once during a 24-hour period for energy conservation.

  • Page 55: Refrigeration

    9. Advance on Button 2 to desired setting 10. Press Button 4 to save – :00 begins flashing (minutes) 11. Advance on Button 2 to desired setting 12. Press Button 4 to save setting – Start 1 or 2 and hh:mm you programmed will display 13.
  • Page 56 11. Advance on Button 2 – Degree F/C 12. Enter on Button 4 – current setting flashes 13. Press Button 2 to scroll between F/C 14. Press Button 4 to save desired setting Fan Default: Default Mode: Fan on/off behaves in same respect as the compressor. Mode 1: Fan is time delayed with compressor cut in/cut out 1.

  • Page 57: Sales Block 1

    16. Press Button 2 to set the hh 17. Press Button 4 to ‘save’ setting – mm flashes 18. Press Button 2 to set: mm 19. Press Button 4 to ‘save’ setting 20. Press Button 1 to exit – Start Time 1 21.
  • Page 58 Choose Selections: 1. Press Button 4 at Selections – All Selections On/Off will display 2. Press Button 4 – On/Off flashes 3. Advance on Button 2 to desired setting 4. Press Button 4 to ‘save’ setting 5. Press Button 1 to exit Set all Selections: 1.

  • Page 59: Discount

    9. Press Button 2 – Start hh:mm 10. Press Button 4 – hh (hour setting) flashes 11. Press Button 2 to advance to desired Start Hour. (Military Time) 12. Press Button 4 to ‘save’ setting -: mm flashes 13. Press Button 2 to advance to desired minutes 14.
  • Page 60 Enable On – Discount function is enabled 2. Press Button 4 – Off flashes 3. Press Button 2 to select desired setting 4. Press Button 4 to ‘save’ setting – Enable ‘On’ will display 5. Press Button 2 – Discounted Selection Set Discount for ‘All’...

  • Page 61: Override

    3. Press Button 4 – Mon-Sun/everyday 4. Advance on Button 2 to desired day 5. Press Button 4 – On/Off flashes 6. Advance on Button 2 to change current status 7. Press Button 4 to ‘save’ setting 8. Set balance of Selections in manner described above 9.

  • Page 62: Custom Message

    Custom Message: The custom message feature allows the operator to program a 2 line X 20 character message. * Note: 1. Press Button 1 to make a space between words. 2. The message cannot be saved until all the characters on the top line have been entered. 1.

  • Page 63: Wiring Diagram

    WIRING DIAGRAM P-31 Part #1167879 08/2008...
  • Page 64 WIRING DIAGRAM (CONT.) P-32 Part #1167879 08/2008...

  • Page 65: Custom Space To Sales Diagram

    CUSTOM SPACE TO SALES DIAGRAM P-33 Part #1167879 08/2008...

  • Page 66: Cabinet Parts

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879               CABINET PARTS SECTION Cabinet Parts Section | C-1 VUE SXY   ...
  • Page 67 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Cabinet Parts Section | C-2 VUE SXY   ...

  • Page 68: Cabinet Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   CABINET ASSEMBLY ITEM DESCRIPTION QTY REQ PART NO. FOAMED CABINET REFRIGERATION ASSEMBLY (SEE PAGE C-4) POWER DISTRIBUTION ASSEMBLY (SEE PAGES C5) ASY,CAB BASE COVER 1160333 ASY,UPPER HINGE 1160216 SCREW, ¼-14 1.0 HEX ZINC PLATE SELF TAP...
  • Page 69 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   REFRIGERATION ASSEMBLY ITEM DESCRIPTION PART NO. REFRIGERATION UNIT ASSEMBLY, 115V 1147845 REFRIGERATION UNIT ASSEMBLY, 230V 1033131-268 FAN MOTOR, 115V 1127974 FAN MOTOR, 230V 1127974-1 FAN ASSY, EVAPORATOR, 115V 1126260 FAN ASSY, EVAPORATOR, 230V 1127994...
  • Page 70 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Cabinet Parts Section | C-5 VUE SXY   ...
  • Page 71 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   POWER DISTRIBUTION ASSEMBLY, 115V ITEM DESCRIPTION PART NO. PWR DIST ASY DOMESTIC 115V 1148125 PWR DIST ASY DOMESTIC 230V 1148137 DISTRIBUTION PANEL 1148114 TRANSFORMER, 115V/24 VAC 1111201 TRANSFORMER, 230V/24 VAC 1121932...

  • Page 72: Harness Quick Guide

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   HARNESS QUICK GUIDE PART NO. DESCRIPTION 1165501 Cabinet Harness 1163345 Cabinet Harness Extension (Required for SXY40 Only) 1165548 Power Distribution Harness, High Voltage 1128750 Power Distribution Harness, Low Voltage 1148058 Fan Motor Harness 1145411...

  • Page 73: Shelves & Trays Parts

    ® SHELVES & TRAYS PARTS SECTION ST-1 Part #1167879 07/2008...
  • Page 74 SHELF AND TRAY ASSEMBLY ITEM NO DESCRIPTION PART NO TRAY ASSEMBLY 1133755 SHELF ASSEMBLY, 41.5” 1125195 SHELF ASSEMBLY, 34” 1136835 ST-2 Part #1167879 07/2008...
  • Page 75 ST-3 Part #1167879 07/2008...

  • Page 76: Tray Assembly

    TRAY ASSEMBLY ITEM DESCRIPTION QTY. PART NO. TRAY ASSEMBLY 1133755 TRAY BODY ASSEMBLY 1131291 TRAY FRONT 1133109 PRODUCT SLIDER, TRAY 1125141 SCREW #8-10 X 1/2” PAN HEAD V802214 PUSHER, TRAY ASSY 1125140 GATE, LEFT, TRAY ASSY 1128285 PIN, PIVOT, TRAY FRONT 1125192 GATE, RIGHT, TRAY ASSY 1128284...
  • Page 77 NOTES ST-5 Part #1167879 07/2008...

  • Page 78: Door Parts

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879               DOOR PARTS SECTION Door Parts Section | D-1 VUE SXY   ...

  • Page 79: Reading A Parts List

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   READING A PARTS LIST ITEM NUMBER is found in two locations: A. It is on the drawing plate, and identifies the part and its location; B.

  • Page 80: Hardware List

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   HARDWARE LIST Door Parts Section | D-3 VUE SXY   ...
  • Page 81 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-4 VUE SXY   ...
  • Page 82 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-5 VUE SXY   ...

  • Page 83: Door Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   DOOR ASSEMBLY ITEM DESCRIPTION PART NO. SERVICE DOOR ASSEMBLY CONTROL PANEL - 2 DBV KNOCKOUTS 1166323 CONTROL PANEL - 1 DBV KNOCKOUT 1143633 CONTROL PANEL - NO DBV KNOCKOUTS 1143682 CAP, SIGN FACE, BOTTOM 1159755...
  • Page 84 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-7 VUE SXY   ...
  • Page 85 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   DOOR ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NO. X-RAIL & X-CARRIAGE ASY (SEE PGS D13-D16) Z-HOUSING & HAND ASY (SEE PG D8) Y-RAIL ASY - HINGE SIDE (SEE PGS D9-D10) Y-RAIL ASY - LATCH SIDE (SEE PGS D11-D12) COINAGE GUIDE MOUNTING BRACKET 1130493...
  • Page 86 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-9 VUE SXY   ...

  • Page 87: Hand Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   HAND ASSEMBLY ITEM DESCRIPTION PART NO. Z HOUSING/HAND ASSEMBLY 1184257 Z HOUSING ASSEMBLY 1133857 HAND ASSEMBLY 1142366 SPRING, DRIVER ASSIST 1127303 ROLLER GUIDE REPLACEMENT KIT 1128060 ROLLER GUIDE 1157825...

  • Page 88: Z Housing Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Z HOUSING ASSEMBLY ITEM DESCRIPTION PART NO. HOUSING - Z AXIS 1128653 RAIL - RIGHT 1125081-1 RAIL - LEFT 1125081 COVER - BACK 1125055 PDC CONTROLLER BOARD 1184714 WIRE ASY, X-MOTOR MATING BOARD 1136264...
  • Page 89 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-12 VUE SXY   ...

  • Page 90: Y Rail Assembly - Left/Hinge Side

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Y RAIL ASSEMBLY – LEFT / HINGE SIDE ITEM DESCRIPTION PART NO. Y-RAIL ASSEMBLY, HINGE SIDE 1133419 EXTRUSION RAIL - Y AXIS - LEFT 1128139 STRIP - DRIVE TRACK - Y AXIS 1128142 BRKT - STOP - Y RAIL...
  • Page 91 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-14 VUE SXY   ...

  • Page 92: Y Rail Assembly - Right/Latch Side

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Y RAIL ASSEMBLY – RIGHT / LATCH SIDE ITEM DESCRIPTION PART NO. Y RAIL ASSEMBLY, LATCH SIDE 1133421 EXTRUSION RAIL - Y AXIS - RIGHT 1128139 STRIP - DRIVE TRACK - Y AXIS 1128142...
  • Page 93 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-16 VUE SXY   ...

  • Page 94: Rail Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   X RAIL ASSEMBLY ITEM DESCRIPTION PART NO. RAIL ASSEMBLY - X AXIS - 41.5” 1184038 RAIL ASSEMBLY - X AXIS - 34” 1184052 EXTRUSION RAIL - X AXIS - 41.5” 1127460 EXTRUSION RAIL - X AXIS - 34”...
  • Page 95 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-18 VUE SXY   ...

  • Page 96: Axis Carriage Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   X AXIS CARRIAGE ASSEMBLY ITEM DESCRIPTION PART NO. CARRIAGE ASSEMBLY - Y AXIS DRIVE 1133561 HOUSING - X CARRIAGE 1136215 X-Z DRIVE MOTOR 1169804 DRIVE WHEEL - X AXIS 1123961 ROLLER GUIDE 1157825...
  • Page 97 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-20 VUE SXY   ...

  • Page 98: Coin Entry & Coin Return Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   COIN ENTRY & COIN RETURN ASSEMBLY ITEM DESCRIPTION PART NO. COIN INSERT, GFV 1125367 LEVER,SCAVENGER ASSY, GFV 1133652 SHOULDER WASHER,NYLON 1122715 SCRW 10-16 5/16 B CR HEX TAP V801422 (K) SPRING SOLD OUT 390326...
  • Page 99 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-22 VUE SXY   ...

  • Page 100: Delivery Hopper & Flap Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   DELIVERY HOPPER & FLAP ASSEMBLY ITEM DESCRIPTION PART NO. DELIVERY BUCKET ASSEMBLY (SEE D23) 1164144 COVER PLATE, DELIVERY BUCKET 1163746 ELECTRIC DOOR SWITCH 323007 NUT, 3/8-32 X 3/32 HEX V801449 SCREW, #10 -16 X 3/8 B CR HEX STL V802047...
  • Page 101 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-24 VUE SXY   ...

  • Page 102: Delivery Hopper Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   DELIVERY HOPPER ASSEMBLY ITEM DESCRIPTION PART NO. BRACKET, DELIVERY BUCKET MOUNTING 1162342 BUCKET, DELIVERY 1164155 FOOTER, DELIVERY BUCKET 1128191 OPTIC DETECTOR ASSY 1130728 SCREW, #10-16 X 3/8 B CR HEX STL V802047 SCREW, # 8-18 X 1/4 V800634...

  • Page 103: T-Handle Lock Assembly

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   T-HANDLE LOCK ASSEMBLY ITEM DESCRIPTION PART NO. T-HANDLE ASSY, GFV 1133778 SHOULDER SPACER, LOCK CAM 1124527 WASHER - 3/8, B PLAIN FLAT V801491 WASHER,13/64, LEWIS#24082-200 389026 SCREW -10-32 X .375, CR PAN H STL MACH V800128...

  • Page 104: Harness Quick Reference Guide

    VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   HARNESS QUICK REFERENCE GUIDE PART DESCRIPTION PURPOSE 1156093 Door Harness Connects all peripherals to control board 1161129 Selection Harness – 12 Select Connects the selection buttons to the control board 1163886 Selection Harness –...
  • Page 105 VUE SXY Parts & Service Manual REV A – 10/2012 Coca-Cola Equipment P/N: 1167879   Door Parts Section | D-28 VUE SXY   ...
  • Page 106 ® MAINTENANCE SECTION Part #1167879 07/2008...

  • Page 107: Maintenance

    MAINTENANCE The following section is a basic guide for general maintenance and servicing of the vendor. This section is divided into three parts: (I) Preventative Maintenance, (II) Lubrication Guide, and (III) Care and Cleaning. PREVENTATIVE MAINTENANCE SUGGESTIONS: Whenever a vendor is visited on its site, the following service should be performed. Preventative maintenance will help prevent future problems with the vendor.

  • Page 108: Refrigeration Operation

    REFRIGERATION OPERATION The refrigeration operation section is divided into three areas: Basic Refrigeration Principle, Detailed Vending Machine Refrigeration Cycle, and Parts Description. BASIC REFRIGERATION PRINCIPLE What a refrigeration system really accomplishes is the transfer of heat. A refrigeration system removes the excess heat from a refrigerated area and then transfers it to a condenser where it is dissipated.
  • Page 109 DETAILED REFRIGERATION CYCLE The following is a detailed refrigeration cycle as it applies to the refrigeration system installed in Vendo equipment. (Refer to the flow chart in Figure 1.) As the air temperature in the cabinet rises, the electronic temperature sensor reports the air temperature to the electronic controller.
  • Page 110 Part #1167879 07/2008...

  • Page 111: Refrigeration Parts Description

    REFRIGERATION PARTS DESCRIPTION The compressor, condenser, drier, capillary tube, evaporator, and accumulator are part of a sealed system (refer to Figure 2). These items are not available separately. COMPRESSOR The compressor takes in low pressure vapor and compresses it, increasing both the pressure and the temperature.
  • Page 112 EVAPORATOR FAN ASSEMBLY CONDENSER CONDENSOR FAN ASSEMBLY COMPRESSOR FIGURE 2 Part #1167879 07/2008...
  • Page 113 The parts listed below are not part of the sealed refrigeration system and are available separately. START CAPACITOR - P/N: 1122999 The start capacitor is used to increase power during the start. This additional power will help get the compressor running in case there is any back pressure. STARTING RELAY –...
  • Page 114 NOTES Part #1167879 07/2008...
  • Page 115 ® TROUBLESHOOTING SECTION Part #1167879 07/2008...

  • Page 116: Parts Return Procedure

    Keep top (white) copy for your records. Attach tag to inoperative part and send it by the most inexpensive method of transportation (Federal Express Ground or Overnight Transportation) To: SandenVendo America, Inc., 10710 Sanden Drive, Dallas, Texas 75238.  Be sure to check ( ) the box marked “credit”...
  • Page 117 Part #1167879 07/2008...
  • Page 118 Part #1167879 07/2008...
  • Page 119 Part #1167879 07/2008...
  • Page 120 Part #1167879 07/2008...
  • Page 121 Part #1167879 07/2008...
  • Page 122 Part #1167879 07/2008...
  • Page 123 Part #1167879 07/2008...
  • Page 124 T-10 Part #1167879 07/2008...
  • Page 125 T-11 Part #1167879 07/2008...
  • Page 126 T-12 Part #1167879 07/2008...
  • Page 127 T-13 Part #1167879 07/2008...
  • Page 128 NOTES T-14 Part #1167879 07/2008...

This manual is also suitable for:

Vendo vue sxy 40

Table of Contents
