  • Page 1 User Guide LAN TESTER...
  • Page 2 According to the European WEEE directive, electrical and electronic equipment must not be disposed with consumers waste. Its components must be recycled or disposed apart from each other. Otherwise contaminative and hazardous substances can pollute our environment. You as a consumer are committed by law to dispose electrical and electronic devices to the producer, the dealer, or public collecting points at the end of the devices lifetime for free.
  • Page 3 2.0 Introduction Lan tester can easily read the correct pin configuration of 10Base-T cable, 10Base-2 cable, RJ45/RJ11 modular cables, 258A, TIA-568A/568B and Token Ring cable etc. by comparing one transmitting end to the corresponding receiving end. With the remote kit it can test cable installed far away either on wall plate or patch panel.
  • Page 4 2.3 Product Profile: Main Unit Remote Unit 1. RJ45 JACK 2. RJ45 JACK 3. LED DISPLAY FOR SOURCING END (JACK l) 4. LED DISPLAY FOR RECEIVING END (JACK 2) 5. POWER SWITCH 6. LED SCANNING MODE SWITCH 7. TEST SWITCH FOR MANUAL SCAN 8.
  • Page 5 3.0 OPERATION 3.1 Loopback Test 10Base-T Cable Test 1. Plug one end of tested cable on sourcing of RJ45 jack (Marked with‘ ') and another end of tested cable on remaining receiving RJ 45 jack. 2. Slide power switch on, the upper row LEDs will start to scan in sequence if the Auto/Manual switch is set on Auto mode, or the LED will light on pin 1 if the Auto/Manual switch is set on Manual mode.
  • Page 6 Modular Cable test Please follow up the procedures of 10Base-T Cable Test. However, the LED display should be read as the right picture. 10Base-2 Cable Test 1. Plug the two attached BNC adaptor cables on both RJ45 jacks, then connect the tested cable both ends on BNC adaptor cables.
  • Page 7 3.2 Remote Test 1. Plug one end of tested cable on the sourcing RJ45 jack (Marked with‘ ') of master unit and another end on the receiving RJ45 jack of remote unit. If the tested cable has already installed on the patch panel or wall plate, you may use the adaptor cable to solve the connector gender problem.
