Page 1: Installation Guide
AVA-1515 AT-to-SCSI Host Adapter Installation Guide... -
Page 2: Getting Started
Location RN1, RN2, RN3 Pin 1 is marked by 1 on the board. Default Settings The AVA-1515 is designed to operate as shipped in most AT-class computers. The default settings are listed on the following page. ® -to-SCSI host adapter. Installa-... -
Page 3: Installing The Host Adapter
IRQ channel of the AVA-1515. Interrupt and IRQ setting must be the same number. If you change the setting you may also need to change options in the soft- ware (see Section 6, Software Installation). -
Page 4: Connecting Peripherals
AVA-1515 SCSI bus. See your SCSI peripheral documentation for directions on how to determine the ID and change it. The default SCSI ID for AVA-1515 host adapters is SCSI ID 7. We recommend that you assign SCSI IDs 0 and 1 to the first two SCSI hard disk drives in your PC. - Page 5 Be sure to maintain correct pin-1 orientation throughout the bus. The AVA-1515 uses a 25-pin DB25 external connector (Apple compatible), and a 50-pin flat ribbon-type internal connector. Terminating the SCSI Bus Cable...
- Page 6 If the system recognizes two standard hard disks, you will need to use the aspi2dos and aspidisk device drivers to access additional SCSI hard disk drives or other devices. See software documentation. AVA-1515 Terminators All three installed All three installed All three removed...
-
Page 7: Troubleshooting Checklist
The AVA-1515 provides booting capability at AT port address 340h-35Fh. If you change this option, disable the BIOS, because the host adapter BIOS supports booting only from the default port address range. Software Installation DOS/Windows Platforms For installing software, insert the software diskette... -
Page 8: Jumper Block Settings
If you need replacement components, such as a fuse, jumper shunt, or terminator, see your dealer. Jumper Block Settings The AVA-1515 jumper block settings are silk- screened on the board and are used to configure user-selectable options. In the diagram on page 1, the black bar covering both pins represents an installed jumper. -
Page 9: Adaptec Customer Support
24 hours a day at 408-945-7727. 1200, 2400, 9600, or 14400 baud, using 8 data bits, 1 stop bit, no parity. For the latest online information about Adaptec products and services, call the Interactive Fax Service 23 hours a day at 408-957-7150. -
Page 10: Fcc Compliance Statement
Each AVA-1515 is equipped with an FCC compliance label which shows only the FCC Identification number. The full text of the associated label follows: This device complies with part 15 of the FCC rules.
