- Page 1 2-wire Intercom System DT6910 user manual Tue. DT-ENG-6910-V1 100S204...
- Page 2 PRECAUTIONS ● ● Read●this●manual●through●before●using●the●product. ● ● Slots●or●openings●in●the●back●of●the●monitor,●are●provided●for●ventilation● and●to●ensure●reliable●operation●of●the●video●monitor●or●equipment●and● to●protect●if●from●overheating.●These●openings●must●not●be●blocked●or● covered.●The●monitor●●should●never●be●placed●near●or●over●a●radiator●or● heat●register●and●should●not●be●placed●in●a●built-in●installation●such●as●a● bookcase●unless●proper●ventilation●is●provided. ● ● All●parts●should●be●protected●from●violence●vibration.●And●not●allow●be● impacting,●knocking●and●dropping. ● ● For●clean●the●LCD●screen,●using●hands●or●wet●cloth●is●forbidden. ● ● Please● do● the● cleanness● with● soft● cotton● cloth,● please● do● not● use● the● organic● or● chemical● clean● impregnate.● If● necessary,● please● use● pure● water●or●dilute●soap●water●to●clean●the●dust.
-
Page 3: Table Of Contents
CONTENT 1.●Door●Camera●DT591-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-1 2.●Electronic●Lock●Connections●- - - - - - - - - - - - - - - - - - - - - - - -2 3.●Door●Camera●Installation● - - - - - - - - - - - - - - - - - - - - - - - - - - -4 4.●Indoor●Monitor ●- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5 5.●Monitor●Mounting●- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5 6.●System●Connection(Basic) ●- - - - - - - - - - - - - - - - - - - - - - - - -6... -
Page 4: Door●Camera●Dt591-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-●-1
1. Door Camera DT591 Parts●and●functions The DT 591 is a special design for the DT 2-wire system: • Full matel cover with backlight nameplate • 4 Door cameras connection • Directly connect 2 separate electronic locks, unlock time controlled by Monitor Camera●Lens Night●View●LED Speaker... -
Page 5: Electronic Lock Connections
• To configure the electronic lock safety type; set the jumper in 1-2 position for Power- Lock Control Jumper: to-Unlock type(pulse activated electronic lock), set the jumper in 2-3 position for the Power-Off-to-Unlock type(electromagnetic lock). Remove the jumper if using external power supply for the lock.(the power+ will be connected to the PL on the Main Connect Port) •... - Page 6 Inner●Power●2●●Locks●Connection Directly connect 2 electronic locks to the door station and use the Camera power to supply the locks. There are 2 separate unlock icons on Monitor for opening each lock. Note that the 2 locks should be the same safety type. 1●●●2●●●3 1●●●2●●●3 Jumper●position●in●1-2...
-
Page 7: Door Camera Installation
3. Door Camera Installation Mounting●Without●Rain●Cover 160-165cm Mounting●With●Rain●Cover 160-165cm Electronic●Specifications Lock Power supply: 12Vdc, 500mA(supplied by system) Power Consumtion: 1W in standby, 12W in working NO, COM exchange contact: Max. 24V dc 3A Unlocking time: 1 to 9 seconds, set by Monitor Working temperature: -5ºC +40ºC - 4 -... -
Page 8: Indoor Monitor
4. Indoor Monitor LCD●screen UNLOCK(▲)●button MONITOR(▼)●button INTERCOM(●)●button TALK(◄)●button MENU(►)●button Microphone Speaker Extend●port BUS●port DIPS 1●2●3●4●5●6 DIP●switches 5. Monitor Mounting Use the screws to fix the Mounting Bracket on the wall.(fitting accesories includes a Bracket (Two 4X25 screws are needed for fastening the Mounting Bracket), Special 2 wire cables to connect with Monitor) Wire the system correctly(see the later connection chapter) then hang the Monitor on the Mounting Bracket firmly. -
Page 9: System Connection(Basic)
6. System Connection(Basic) Note●1 Note●2 Note●4 DIPS L1●●L2●●PL●●S1+●●S2+●●S- Note●3 1●2●3●4●5●6 Note●5 Note●6 Note●7 ● Note 1: When only one Door camera installed, set both the bit-1 and bit-2 to OFF state. ● Note 2: Mount the DPS and PS4 side by side on the DIN nail or on the wall. ●... -
Page 10: Monitor Operation Introduction
7. Monitor Operation Introduction In this Monitor, all the icons on the screen has a corresponding button, and each button has a corresponding LED indicator; the LED indicator also has a state-sencitive feature for easy operation. play When the screen showing the menus, press monitor the corresponding buttons to enter the sub intercom... -
Page 11: Talk/Unlock Operation
8. Talk/Unlock Operation When visitor presses the Call Button on the Outdoor Station, the monitor rings, at the same time, the screen displays the visitor image. Unlock icon Talk icon. Camera switch icon Setting icon. Exit icon Press TALK ◄ Button, you can talk with the visitor for 90 seconds. During talking state, press the TALK ◄... -
Page 12: Ring Tone Setting
9. Ring Tone Setting 10. Monitor Time Setting 15●pieces●ring●tone●can●be●selected.●When● Monitor● Time● is● the● maximum● monitoring● ► Button ▼ the●Monitor●is●in●standy,●press●● ,●a● time● when● the● MONITOR● Button● is● full●screen●calendar●will●be●showed. pressed● in● standby,● after● which● the● screen● will●be●closed●automatically. ► When● the● Monitor● is● in● standy,● press● ● Button ●to●open●the●screen. -
Page 13: Time Setting
12. Screen Setting 11. Time Setting ► When●the●Monitor●is●in●monitoring●or●talking,● When● the● Monitor● is● in● standby,● press● ► Button Press● ● to● open● the● screen● setting● Button ► Button ● to● open● the● screen,● press● ● menu. again● to● enter● the● main● menu.●Then● press● ◄... -
Page 14: Slave Address Setting
13. Slave Address Setting 14. Restore to Default When● multiple● Monitors● installed(maximum● The● restore● to● default● function● allows● the● 4● Monitors● can● be● installed),● the● Slave● user● to● recover● the● settings● to● factory● Address●must●be●set.●Set●to●0●for●the●master● setting. Monitor,●set●to●1/2/3●to●the●other●Monitors.●If● ► When● the● Monitor● is● in● standby,● press● only●one●Monitor●is●installed,●set●to●0. -
Page 15: Intercom Function
15. Intercom Function 16. Unlock Mode Setting When●multi●Monitors●are●installed,●intercom● The●Unlock●Mode●is●for●electronic●lock●type● function● is● available.● Intercom● call● can● be● setting,●when●connect●Power-to-Unlock●type● started● by● any● Monitor.● When● a● intercom● lock(s),● set● the● Unlock● Mode● to● 0(which● is● call●has●been●started,●all●other●Monitors●will● the● default● setting),● when● connect● Power- ring●at●the●same●time,●if●one●called●Monitor● off-to-unlock●type,●set●the●Unlock●Mode●to●1. -
Page 16: Multiple Monitors Connection
17. Multiple Monitors Connection Note●1 Note●2 Note●3 Note●4 1#●Monitor 2#●Monitor 3#●Monitor 4#●Monitor DIPS DIPS DIPS DIPS 1●2●3●4●5●6 1●2●3●4●5●6 1●2●3●4●5●6 1●2●3●4●5●6 Note●5 Note●7 Note●6 L1●●L2●●PL●●S1+●●S2+●●S- ● Note 1: The on the 1# Monitor set to 0. Slave Addr Set ● Note 2: The on the 2# Monitor set to 1. -
Page 17: Multiple●Monitors●Connection
18. Multiple Monitors Connection Note●1 4#●Monitor 3#●Monitor 2#●Monitor 1#●Monitor DIPS DIPS DIPS DIPS 1●2●3●4●5●6 1●2●3●4●5●6 1●2●3●4●5●6 1●2●3●4●5●6 4#●Camera 3#●Camera 2#●Camera 1#●Camera Note●3 L1●●L2●●PL●●S1+●●S2+●●S- L1●●L2●●PL●●S1+●●S2+●●S- L1●●L2●●PL●●S1+●●S2+●●S- L1●●L2●●PL●●S1+●●S2+●●S- Note●2 ● Note 1: The settings for all the Monitors are the same as chapter 16 Multiple Monitor connections. -
Page 18: Extend Functions
19. Extend Functions 1.●Door●Bell●Call●Button Additional●door●bell●call●button●can●be●connected● to● the● ● Monitor,● so● that● the● visitors● can● ring● the● door● bell● again● in● front● of● the● user's● apartment.● EXT-RING When●the●call●button●is●pressed,●the●Monitor●will● Door●bell●call●button VIDEO output●ring●tones●but●the●screen●will●keep●off,●and● the●external●ringer●will●ring●at●the●same●time(if●a● external●ringer●is●installed). 2.●External●Ringer External●Ringer External●ringer●can●be●connected●to●the●Monitor.● The●ringer●will●ring●whenever●the●Door●Station●call● button●or●the●door●bell●call●button●is●pressed,●and● it● will● stop● ringing● when● the● Monitor● rejucted● or● EXT-RING answered●the●call. -
Page 19: Specifications
20. Specifications ● ● Power●supply●for●indoor●monitor:●● ●● DC●24V●(supplied●by●Adaptor) ● ● Power●supply●for●Door●Camera:● ● DC●24V●500mA ● ● Power●consumption:● ● Standby●0.5W;●Working●status●15W ● ● Monitor●screen:● ● 7●Inch●color●TFT-LCD ● ● Display●Resolutions:● ● 1,440(R,●G,●B)●x●234●pixels ● ● Monitor●time:● ● 30●seconds●to●10●minutes ● ● Talking●time:● ● 30●seconds ● ● Monitor●Dimensions:● ●... - Page 20 The●design●and●specifications●can●be●changed●without●notice●to●the●user.●Right●to● interpret●and●copyright●of●this●manual●are●preserved. DT-ENG-6910-V1 100S204...
