5. ccRF click Board Schematic
™
VCC3.3
VCC3.3
AN
RF-GDO0
RST
R2 RF-CS#
CS
2K2 RF-SCLK
SCK
RF-SO
MISO
RF-SI
LD1
MOSI
+3.3V
GND
FP1
VCC3.3
C8 C9 C10 C11 C12
10uF 100nF 100nF 220pF 220pF
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specification and information contained in the present schematic are subject to change at any time without notice. Copyright © 2013 MikroElektronika. All rights reserved.
Arrow.com. Arrow.com.
Downloaded from Downloaded from
VCC-RF
RF-GDO2
PWM
RF-SCLK 1
INT SCLK
RF-SO 2
TX SO
RF-GDO2 3
RX GDO2 CC2500
4
SCL DVDD
GND
5
SDA DCPL
+5V
GND
C7
100nF
VCC-RF
C13 C14
100nF 100nF
R1 56K
U1
C1 100pF C2 1pF
15
AVDD
14
AVDD
13 C3 100pF
RF_N
12
RF_P
11 L2 1.2nH
AVDD
L3
C6
1.2nH
1pF
R3 10K
R4 1M
X1
26MHz
C15 C16
22pF 22pF
6. PCB Trace Antenna
Board features PCB trace antenna, designed
for the 2400-2483.5 MHz frequency band.
Maximum device range is up to 20 meters in
open space.
7. Code Examples
A1
IFA_2.4GHz
L1 1.2nH
ANT
Once you have done all the necessary
preparations, it's time to get your click
C4 C5
1.8pF 1.5pF
board up and running. We have provided
the examples for mikroC
mikroPascal
website. Just download them and you are
ready to start.
8. Support
MikroElektronika offers
(www.mikroe.com/esupport)
of product lifetime, so if something goes
wrong, we are ready and willing to help!
™
, mikroBasic and
™ ™
compilers on our Libstock
™
.com
Free Tech Support
until the end
