Normal Takeoff (Flaps 0°); Short-Field Takeoff & Climb (Flaps 25°) - ATP Electronics Piper Archer Training Supplement

Normal Takeoff (Flaps 0°)
Do not delay on runway.
1. Line up on centerline positioning controls for wind
2. Hold brakes
3. Increase throttle to 2000 RPM
4. Check engine gauges
5. Release brakes
6. Increase throttle to full power
7. "Airspeed Alive"
8. Start slow rotation at 60 KIAS
9. Accelerate to 76 KIAS (V
10. "After Takeoff Checklist" out of 1,000' AGL
Normal Takeoff Profile
Lined Up on Runway Centerline
Short-Field Takeoff & Climb (Flaps 25°)
1. Flaps 25°
2. Hold brakes at departure end of runway
3. Increase throttle to 2000 RPM
4. Check engine gauges
5. Increase throttle to full power
6. Release brakes
7. "Airspeed Alive"
8. Begin rotation at 55 KIAS to climb at 64 KIAS (V
9. At safe altitude, slowly retract flaps.
10. Accelerate and climb at 76 KIAS (V
11. "After Takeoff Checklist" out of 1,000' AGL
18 • Departure Procedures
)
Y
Approx.
"Airspeed Alive" 65 KIAS
60 KIAS
V Lift-O
R
ATP Archers are equipped with traffic information. It is not to be
used as a collision avoidance system and does not relieve the
pilot of responsibility to "see and avoid" other aircraft.
) over a 50' obstacle
X
) when clear of obstacles
Y
"After Takeo Checklist"
1,000' AGL
