SECTION 2
Performance / Weight & Balance

Piper Archer V-Speeds

Speeds listed below are in Knots Indicated Airspeed (KIAS).
V-Speed KIAS
V 45
SO
V 50
S
V 60
R
V
64
X
V
76
Y
V
76
G
V
102
FE
V
125
NO
V
154
NE
V
113
A
V
89
A
Maximum demonstrated crosswind 17 knots

Performance Charts

All performance charts will be covered by the instructor and are not limited to
the following:
• Flaps Up Takeoff Performance
• 25° Flaps Takeoff Performance
• Engine Performance
• Glide Range
• Landing Performance
14 • Performance / Weight & Balance
Description
Stall speed in landing configuration
Stall speed with zero flaps
Rotation speed (start rotation)
Best angle of climb
Best rate of climb
Best glide speed at max weight
Maximum flap extension speed
Max Structural Cruising Speed
Never exceed speed
Maneuvering speed at 2,550 pounds
Maneuvering speed at 1,634 pounds
Airspeed
Indicator Marking
Bottom of White Line
Bottom of Green Line
Top of White Line
Top of Green Line
Red Line
