USER MANUAL
FR : Un manuel dans votre langue est disponible sur Internet:
IT: Il manuale nella sua lingua può essere trovato su Internet:
ES: Puede encontrar un manual en su idioma en Internet:
PT: Um manual em seu idioma pode ser encontrado na Internet:
PL: Instrukcję w swoim języku możesz znaleźć na stronie:
SWE: En handbok på ditt språk finns på Internet:
NL: Een handleiding in uw taal vindt u op internet:
www.easypix.info/download-manuals/download/gs1/
Advertisement
Table of Contents
Related Manuals for Easypix GoXtreme GS1
Summary of Contents for Easypix GoXtreme GS1
- Page 1 PT: Um manual em seu idioma pode ser encontrado na Internet: PL: Instrukcję w swoim języku możesz znaleźć na stronie: SWE: En handbok på ditt språk finns på Internet: NL: Een handleiding in uw taal vindt u op internet: www.easypix.info/download-manuals/download/gs1/...
-
Page 2: Table Of Contents
Table of content Retaining instructions ................3 Explanation of safety warnings ..............3 Product introduction ................4 Intended use ..................4 Restrictions .................... 4 Safety instructions .................. 5 Operating environment ................6 Description of the product ..............7 Using your gimbal ................... 8 Step 1: Unfold the gimbal ................ - Page 3 Easypix is not responsible or liable for misuse of the information that is contained herein. If you have any suggestions for improvements or...
-
Page 4: Retaining Instructions
Retaining instructions Read this manual and its safety instructions before using this product. Follow all the instructions. This will avoid fire, explosions, electric shocks or other hazards that may result in damage to property and/or severe or fatal injuries. The product shall only be used by persons who have fully read and understand the contents of this user manual. -
Page 5: Product Introduction
Product introduction The GS1 gimbal is a high quality single-axis motorized gimbal, tripod and selfie stick with removable remote control. The 3 in 1 functionality ensures you capture smooth and stable videos and photos with your smartphone. Fixing an action cam to the gimbal you can also capture selfie shots (photos and videos). -
Page 6: Safety Instructions
Safety instructions WARNING This product is only suitable for the purpose described, the manufacturer is not liable for damage caused by abnormal use. WARNING Please read this instruction manual carefully before use, and ensure the remote control unit battery is installed correctly. •... -
Page 7: Operating Environment
Operating environment • Do not expose the device to abnormally high or low temperatures. Store the device cool (at room temperature) in a dry and dust- free location and never expose the product to high temperatures or direct sunlight. • Protect the product from falls, shock and impact. -
Page 8: Description Of The Product
Description of the product 1. • Power On/Off • Inserting the smartphone (90°) 2. LED indicator 3. Gimbal motor 4. Micro USB socket 5. Screw cap 6. Selfie stick adjustment 7. Remote LED indicator 8. Shutter button 9. Tripod... -
Page 9: Using Your Gimbal
Using your gimbal Your gimbal is designed for use in a variety of applications whether you are at home or on the move. To ensure your gimbal configures itself correctly for use, always place your smartphone into the holder before switching the device on. For best stabilization performance, when inserting the smartphone into the clamp, always try to place it in the centre of the clamp for the best balance. - Page 10 WARNING • To avoid the risk of electric shock, do not insert the power cord with wet hands. • In the unlikely event of overheating, smokes or unpleasant odours coming from the unit, disconnect it immediately from the charging cable. •...
-
Page 11: Step 3: Remote Bluetooth Paring
Step 3: Remote Bluetooth paring You can slide the remote control upwards to remove it from the handle and use it remotely at a distance of up to 10m. • Remove the plastic tab completely to allow the battery to connect. -
Page 12: Step 4: Inserting The Smartphone
Step 4: Inserting the smartphone Please make sure that the cradle is no longer engaged and that the smartphone is centred. -
Page 13: Step 5: Selfie Stick Or Tripod
Step 5: Selfie stick or tripod Extend the Selfie stick or set up the stand. Step 6: Switch on the gimbal • With the smartphone in position, turn on the stabilizer by long- pressing the power button for 3 sec. •... -
Page 14: Step 7: Changing The Orientation
Step 7: Changing the orientation Short-press the power button to change the position of the gimbal from horizontal to vertical. Please note: If you turn the position several times, the bracket will snap in and the gimbal will automatically switch off. Step 8: Switch off the gimbal Turn off the stabilizer by long-pressing the power button for 3 sec. -
Page 15: Change The Remote Control Battery
Change the remote control battery To change the battery, open the remote control using the recess on the side. You will need a new CR1632 battery. 1. Extend the selfie stick 2. Slide the remote upwards to remove it 3. Open the top cover of the remote control 4. -
Page 16: Box Contents
Devices containing built-in batteries should be disposed of in accordance with applicable local regulations, and you should not throw them into household garbage to avoid irreversible pollution. Box contents • Gimbal • USB cable • Manual EN/DE Manuals in further languages are available for download here: www.easypix.info/download-manuals/download/gs1/... -
Page 17: Technical Specifications
Technical specifications Foldable 1-Axis gimbal with: - Extendable Selfie Stick GS1 Gimbal - Tripod - Bluetooth remote control Rotating 90° horizontally/vertically Built-in battery Li-Ion 400mAh Charging port Micro-USB Charging voltage Working current 50-900mA Operational time 2-3 Hours Charging time 2 Hours Remote control Bluetooth BLE 4.2 Remote control range... -
Page 18: Disposal
The recycling of materials will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and environment. Declaration of conformity The EC Declaration of Conformity for GS1 Gimbal can be downloaded here: www.easypix.info/download/pdf/doc_gs1.pdf...
