Savant SIS-5000S-00 Quick Reference Manual

Savant® Intercom Server
Quick Reference Guide
The Savant® Intercom Server enables 3rd Party Intercom Door/Gate
entry products and intercom enabled iOS devices to create a
Savant® Intercom Server Solution that integrates easily into an
existing Savant Control System. Once installed and configured, the
Savant Intercom can communicate with various 3rd Party Intercom
Door/Gate entry systems to supply audio and/or video of the
entrance to your facility or home.
This Quick Reference Guide gives basic information about the
Savant Intercom along with initial installation and wiring procedures.
Once installed and connected, refer to the
Intercom Deployment Guide for configuration and integration
procedures.

Box Contents

(1) Savant Intercom Server (SIS-5000S-00)
(1) Power cord
(1) Quick Reference Guide (this document)

Supported Devices

1U Rack System (RCK-3000-xx)
•
3rd Party Door Entry systems
•
Holovision Analog Intercom Door/Gate Entry
•
Holovision VoIP Intercom Door/Gate Entry
•
Siedle Analog Intercom Door/Gate Entry
•
Mobotix VoIP Intercom Door/Gate Entry
•
Savant TrueControl™ II for iOS
•
TEL-IAD2-xx Integrated Access Device (Analog to VoIP
•
conversion)
PAS-1000-xx Public Announcement System
•
Specifications
Environmental Environmental
Operating: 50° to 95° F (10° to 35° C)
Temperature Temperature
Storage: -40° to 116° F (-40° to 47° C)
Humidity 5% to 95% RH (non condensing)
Cooling 15 cubic feet per minute (CFM) recommended
Noise 12dBA at idle
Dimensions and Weight Dimensions and Weight
Height 1.4 in (3.6 cm)
Width 7.7 in (19.7 cm)
Depth 7.7 in (19.7 cm)
Weight 2.6 lb (1.20 kg)
Rack Space 1U
Power Power
Input Power 100-240V AC 50/60Hz
Maximum Power 85W
Memory Memory
Memory 8 GB
Compliance Compliance
Safety and
FCC Part 15 | CE Mark | C-Tick
Emissions
RoHS Compliant
Minimum Supported Release Minimum Supported Release
Savant OS da Vinci 7.0.2
SIS-5000S-00 | 009-1302-01 | 150626 SIS-5000S-00 | 009-1302-01 | 150626
Copyright © 2015 Savant Systems, LLC
Savant SIS-5000S-xx
1

Front Panel

Power LED Illuminates white when host is powered On.

Rear Panel

Power On: Press while powered Off
Power Off:
1. Launch a Terminal window from the SDE.
2. SSH into the SIS-5000S:
3. Enter default password: RPM.
Power Button Power Button
4. At the prompt, enter shutdown command:
5. When prompted, enter the default password
6. Verify the SIS-5000S Power LED is off.
7. Unplug the SIS-5000S.
Power Input 100-240V AC 50/60Hz
10/100/1000 Gigabit Ethernet Port. Connect
Ethernet to a managed Ethernet switch within your
local network.
Output for cooling of the internal processor.
Cooling Vents
DO NOT BLOCK
Note: Connections not identified in the diagram above are not
functional within a Savant Configuration/Installation.

Power Management Recommendations

Savant recommends a pure sine wave uninterruptible power supply
(UPS) with the ability to shut down the SIS-5000S before the
battery runs out of power. Never remove power from the
SIS-5000S before shutting it down.

Additional Documentation

Refer to the following documents located on the Savant Customer
Community for for additional information.
Savant intercom Server (SIS-5000S) Deployment Guide
•
of 2
ssh RPM@<ip_of_ SIS5000S>
sudo shutdown -­‐P now
again: RPM.
45 Perseverance Way, Hyannis, MA 02601
savant.com | 508.683.2500
For Product Info
