Operation

① Check the machine and accessories, ensure it is in good status. Place the machine on a flat surface, tilting may result
in inaccurate water level alarm.
② Fill the liquid tank with FX-M Pro medium fog fluid. Please use original fog fluid from SHOWVEN, Warranty will be
void if any other type fog fluid is used.
③ Connect the machine to suitable rated power supply. Please ensure power supply meets the requirement. Always
connect the machine to a protected circuit and ensure it is properly grounded.
④ Turn on the machine, it heat up automatically, and shows "WARMING UP" on LCD screen.
⑤ Fill the outer water tank with pure water until there is alarm of water shortage on LCD screen (E3, E4). Operator
can also connect the machine to water supply with G1/6 pipe connector, machine will refill it automatically.
⑥ Once the machine has reached operating temperature, temp., fog output and fan speed will show on the screen,
please adjustable it accordingly.
⑦ Press "+"to start making fog, press "ENTER"to stop.
⑧ To turn off the machine, please POWER OFF and unplug the power cable.
⑨ For transportation please drain the machine.

DMX Control

2 channel mode
Channel
First Channel（CH1）
Second Channel（CH2）
3 channel mode
Channel
First Channel（CH1）
Second Channel（CH2）
Third Channel（CH3）
6
Function
Fog output: DMX VALUE 6-255, fog output from 1-100.As volume increase, the
denser the fog, the longer for dissipate.
Fan speed: DMX VALUE 6-255, fan speed from 1-100. As volume decrease, the
better the fog stick to the ground but spread slower.
Function
Fog output: DMX VALUE 6-255, fog output from 1-100
Fan speed: DMX VALUE 6-255, fan speed from 1-100
Ultrasonic atomizer QTY manual control:（0~127）atomizer QTY is 3（CREEPER AQ
is 2）（128~255）atomizer QTY is 4（CREEPER AQ is 3）
