- Page 1 1 of 20 User Guide PRO469 Manual 2021 v1.indd 1 PRO469 Manual 2021 v1.indd 1 15/1/21 9:40 am 15/1/21 9:40 am...
-
Page 2: Table Of Contents
Dual Pump Selection Display Contrast Water Budgeting and Seasonal Adjustment Fault Indication Feature System Test Clearing the Programs Program Rescue Feature 2 of 20 PRO469 Manual 2021 v1.indd 2 PRO469 Manual 2021 v1.indd 2 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 3: Introduction
Introduction Features Your PRO469 Multi-Program Irrigation Controller L 6 and 9 station models is available in 6 and 9 station configurations. L Toroidal high capacity transformer Designed to cover a wide range of applications rated to 1.25AMP (30VA) from residential and commercial turf, to light agriculture, and professional nursery. -
Page 4: Overview
Overview 7. MAIN DIAL 1. LCD display 8. SENSOR switch 9. Terminal cover 4 of 20 PRO469 Manual 2021 v1.indd 4 PRO469 Manual 2021 v1.indd 4 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 5: Programming
ΠThe MAIN DIAL is the primary device for selecting an operation to select different PROGRAMS. Each push ΠPress on this button will increment one PROGRAM number 5 of 20 PRO469 Manual 2021 v1.indd 5 PRO469 Manual 2021 v1.indd 5 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 6: Set Start Times
2 days time ΠThe next active day is always changed to 1, meaning tomorrow is the first active day to run 6 of 20 PRO469 Manual 2021 v1.indd 6 PRO469 Manual 2021 v1.indd 6 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 7: Set Run Times
0, and the display will flash OFF as shown above L This completes the setup procedure for PROG No. 1 7 of 20 PRO469 Manual 2021 v1.indd 7 PRO469 Manual 2021 v1.indd 7 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 8: Manual Operation
ΠWhen running programs in this mode the when the dial is turned to RUN STATION BUDGET % will alter the RUN TIMES of each individual station accordingly 8 of 20 PRO469 Manual 2021 v1.indd 8 PRO469 Manual 2021 v1.indd 8 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 9: Other Features
ΠIf the AC power is off, the display will not be visible 9 of 20 PRO469 Manual 2021 v1.indd 9 PRO469 Manual 2021 v1.indd 9 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 10: Rain Delay
4. To return to the clock, turn the dial to AUTO 5. If the BUDGET% for your current month is not 100%, this will be shown in the AUTO clock display 10 of 20 PRO469 Manual 2021 v1.indd 10 PRO469 Manual 2021 v1.indd 10 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 11: Fault Indication Feature
ΠThe system test will begin automatically ΠThe clock will be retained, and the other functions for setting START TIMES, L Your PRO469 will water every station WATERING DAYS and RUN TIMES will be sequentially for 2 minutes each cleared and returned to the start up settings 2. -
Page 12: Installation
Ÿ Serious injury or death could result from improper hook up–if in doubt consult your regulatory body as to what is required 12 of 20 PRO469 Manual 2021 v1.indd 12 PRO469 Manual 2021 v1.indd 12 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 13: Terminal Block Layout
ΠIt is used like a back-up valve or fail safe device and is installed at the start of the irrigation system where it is connected to the water supply line 13 of 20 PRO469 Manual 2021 v1.indd 13 PRO469 Manual 2021 v1.indd 13 15/1/21 9:40 am... -
Page 14: Station Valve Installation
Œ To install a rain sensor, wire it between the Common (C) and the Rain Sensor (R) terminals as shown L 200–400m cable dia 2.0mm 24VAC RAIN SENSOR: OPTIONAL 14 of 20 PRO469 Manual 2021 v1.indd 14 PRO469 Manual 2021 v1.indd 14 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 15: Pump Start Relay Connection
ΠIt is recommended to always use a relay between the controller and the pump starter 24VAC 24VAC AC RELAY PUMP MOTOR MAGNETIC STARTER 1 2 3 4 POWER SUPPLY 15 of 20 PRO469 Manual 2021 v1.indd 15 PRO469 Manual 2021 v1.indd 15 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 16: Troubleshooting
Pump not working on a specific Programming error with Check programming, using the manual station or program pump enable routine as a reference and correct mistakes 16 of 20 PRO469 Manual 2021 v1.indd 16 PRO469 Manual 2021 v1.indd 16 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 17: Electrical Specifications
To the Master Valve/Pump Start: L 24VAC 0.25 amps max ΠTransformer and fuse capacity must be compatible with output requirements 17 of 20 PRO469 Manual 2021 v1.indd 17 PRO469 Manual 2021 v1.indd 17 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 18: Servicing
٠Tampering with the unit will void the warranty. 9. Replace your controller panel by reversing this procedure. ΠThe controller should always be serviced by an authorised agent 18 of 20 PRO469 Manual 2021 v1.indd 18 PRO469 Manual 2021 v1.indd 18 15/1/21 9:40 am 15/1/21 9:40 am... -
Page 19: Warranty
As well as your statutory rights referred to above and any other rights and remedies you have under any other laws relating to your Holman product, we also provide you with a Holman guarantee. Holman guarantees this product against defects caused by faulty workmanship and materials for 3 years domestic use from the date of purchase. - Page 20 Keep up to date to with relevant product information and special offers available through our newsletter. www.holmanindustries.com.au/product-registration/ Thanks again for choosing Holman PRO469 Manual 2021 v1.indd 20 PRO469 Manual 2021 v1.indd 20 15/1/21 9:40 am 15/1/21 9:40 am...
