Installation & User Instructions:
Models:
Amathus,Albany,Almyra,Brooklyn,Cestino,Casal,Caleta,Costanza,Casis,Fusion,Harlem,
Iowa,Londa,Nebraska,Phantom,Ridgewood,Seraph,Saphir,Soul16,Scala,Tiago
Once installed, the installer should take the appropriate steps
To ensure that the user understands how the appliance operates and
Should make the customer aware of the appliances basic service requirements.
Advertisement
Related Manuals for Evonic Fires Amathus
Summary of Contents for Evonic Fires Amathus
- Page 1 Installation & User Instructions: Models: Amathus,Albany,Almyra,Brooklyn,Cestino,Casal,Caleta,Costanza,Casis,Fusion,Harlem, Iowa,Londa,Nebraska,Phantom,Ridgewood,Seraph,Saphir,Soul16,Scala,Tiago Once installed, the installer should take the appropriate steps To ensure that the user understands how the appliance operates and Should make the customer aware of the appliances basic service requirements.
- Page 2 All Evonic fires products meet the requirements of the EC Directives 2004/108/EC and 2006/95/EC. These directives have been met by compliance with the following standards: BS EN 60335-1:2002 BS EN 60335-2-30:2003 BS EN 6100-6-3:2001 Please read these instructions before installation or use and keep this booklet handy for future reference.
- Page 3 Replacement plug: (Please note that it may invalidate your warranty is the moulded plug is removed) This appliance must only be connected to a 230/240 Volts AC 50Hz supply. Before connecting the fire, check that the supply voltage is the same as stated on the fire.
- Page 4 (Please ensure that the appliance is disconnected from the mains supply before proceeding). Models: Amathus,Casis,Seraph,Phantom The above models use x1– STD Bayonet 20W Energy saving lamps. To change the bulbs in this product you must first remove all pebbles,coals,logs or embers from the orange fuel bed.
-
Page 5: Installation Requirements
INSTALLATION REQUIREMENTS: INSET MODELS: This product has been designed to be installed into a standard 420mm(W) x 570mm(H) x 100m(D) If the products is to be installed into a open chimney or flue, it is important that the chimney/flue is blocked off to prevent any up/down draughts and falling debris which could restrict and alter the airflow to the product. - Page 6 OPERATING INSTRUCTIONS The appliance can be operated manually using the rocker switch to the left of the heater outlet, or by remote control. To operate, first press the right master switch (located on the right underside of the flame screen of the product) which is marked (O/I) to the ( I ) position then perform the following actions: FLAME EFFECT ONLY (NO HEAT) Manual –...
- Page 7 Installation: Wall Mounted Models. Evonic Fires Ltd recommends that heavy duty wall anchors or equivalent to Medium or Heavy weight Approved are used when installing on to hollow/studded walls) Inset Opening sizes: - (Almyra/Scala) = Minimum Height 545mm x width 545mm.This measurement includes a 15mm aeration gap around the product.
- Page 8 EVOFLAME Fuel layout: EVOFLAME products can be supplied with different fuel types. In order to optimize the products flame effect, evonic fires suggest that the below fuel layouts are followed. LOG & PEBBLE FUEL SET. SUGGESTED LAYOUT = SMALL LOG FUEL SET.
- Page 9 Call-Out by our appointed service engineer. This warranty is in addition to and does not affect the purchasers statutory rights of consumers. Evonic Fires Ltd 1 Stour house, Clifford park, Clifford lane, Stratford-Upon-Avon, CV37 8HW Tel: +44 (0) 1789 263868 Fax: +44 (0) 1789293080...
-
Page 11: Extended Warranty
Please submit this form along with a copy of receipt or invoice to the below address: PLEASE NOTE THAT WARRANTY FORMS SUBMITTED WITHOUT A COPY OF RECEIPT OR INVOICE WILL BE NIL AND VOID. Evonic Fires Ltd 1 Stour house, Clifford park, Clifford lane, Stratford-Upon-Avon, CV37 8HW...
Need help?
Do you have a question about the Amathus and is the answer not in the manual?
