Hardware Specifications; Ordering Information - Fastora NAS-104 Specifications

Product Highlights and
Benefits
Top View

Hardware Specifications

Back View

Ordering Information

NAS – 104
• Reliability
– 4 ATA-133 Hot-Swappable HDD bays
– Supports RAID 0, 1, 5 and 5 with Hot-Spare
– Redundant Hot-Swappable power supplies available
– N-Way OS Mirroring secures data no mater if any HDD fails
– Hardware Monitoring, Auto-notifications, and Logging
– Dual 10/100 Map Ethernet with fail-over capability
– UPS (Uninterruptible Power Supply) support through serial port & SNMP Trap
• Performance
– Dual 10/100 Mbps Ethernet with trunking capability
– Gigabit Ethernet (auto-sensing) Support
– RAID 5 Device Layer Cache Support with 20% performance enhancement
• Scalability
– 1U Rack-mount design
– Volume concatenation support(*)
– Network Resilience-multi-subnets support
(*)Available with FASTORA Filer software for Enterprise Businesses
• Cost-Saving
– Hot-Swappable IDE HDD Interface, costs at least 30% lower than SCSI
– Affordable initial setup cost and competitive incremental cost
• Flexibility& Interoperability
– Mulit-Protocol system supports on Microsoft, Apple, UNIX/LINUX, and Novell networks
– Design for integration into Microsoft NT 4.0/2000 domain and NIS domain
• Security
– FASTORA Filer Backup to secure the data of NAS
– FASTORA Data Replicator to secure the data of client
– SCSI local backup function available
• Simplicity
– Friendly Browser-Based Graphic User Interface (GUI)
– Powerful and easy-to-use FASTORA Filer software for management
Form Factor 1U rack-mount/stacked-up on desktop design
Capacity From 0 to 640GB and beyond, depending on hard disk drive capacity
Power Supply Single or Redundant 250W ATX power supplies
4 X Hot-Swappable Enhanced IDE HDD bays
Hard Drive
2 x 10/100 Base-T Ethernet LAN port
Rear Panel Connector
1 x Gigabit Ethernet LAN port (via an optional mini-PCI adaptor)
1 x COM port
1 x SCSI port (via an optional mini-PCI adaptor)
Front Panel LED 4 x LEDs for HDD's / 2 x LEDs for LANs
1 x LED for System / 1 X LED for Alarm
1 x push-button for system reset
1 x push-button for power on/off
Processor Intel PIII CPU Architecture
Main Memory One PC100/133 SDRAM DIMM (supports up to 512MB)
IDE Interface Two onboard IDE controllers to support four bus mastering ATA 66/100/133
Enhance IDE channels
One UART
Serial Port
Ethernet Two 10/100 Base-T Ethernet and optional Gigabit Ethernet Supporting
Fail-over and Trunking
Expansion Three mini-PCI bus connectors for IDE, SCSI, and Gigabit Ethernet adaptor expan-
sion
One IDE interface CompactFlashTM socket for embedded O.S.
Compact-FlashTM
Detection for six Fans, and for the CPU thermal temperature monitoring
Hardware Monitoring
Dimensions 482.6mm (19")(W) x 44mm(1.75")(H) x 520mm(20.5")(D)
Weight Approx. 8.7kg (Single Power) / 10.4kg (Dual Power), without hard drive
Operation environment Air temperature: 10ºC – 35ºC
Humidity: 8% – 90%
Air temperature: -20ºC – 65ºC
Storage environment
Humidity: 8% – 90%
Model Number
NAS-104B: Dual 250W ATX power supply / Celeron 1.2GHz /256MB DIMM/ Gigabit
