Tavistock SL44AL Installation & Aftercare Instructions

SLEEK ILLUMINATED CABINET
INSTALLATION & AFTERCARE INSTRUCTIONS
SL44AL
SL60AL
Customer Services
Tavistock, Brassmill Lane Trading Estate, Bath, BA1 3JF
t. 01225 787 870 e. info@tavistock-bathrooms.co.uk w: www.tavistock-bathrooms.co.uk
ELECTRICAL SAFETY INSTRUCTIONS
(Applicable to UK Installations only)
All fittings must be installed by a competent person, in accordance with current IEE
wiring regulations. If in doubt consult a qualified electrician
IMPORTANT
Always switch off the electrical supply at the mains during installation and
maintenance. It is recommended that the fuse is withdrawn or the circuit breaker is
switched off for the necessary circuit before installation commences.
Fitting in Bathrooms is subject to the appropriate zone in accordance with IEE
Regulations. This product is suitable for zone 2 and outside zones. IT IS NOT suitable
for installation in Zone 0 or Zone 1. It is also not suitable for installation in saunas,
steam rooms or shower cubicles. This product is only suitable for permanent
installation. DO NOT connect to a trailing plug and socket outlet. Although this
product has an Ingress Protection rating of IP44 it is only suitable for indoor use. Do
not attach the product to surfaces that are damp or otherwise electrically conductive.
INSTALLATION CARE & SAFETY
Wear suitable eye protection when drilling. Take care when using power tools near
water - the use of a residual current device (RCD) is advised. Beware of hidden cables
or pipes. Take care if drilling on tiled surfaces in case the drill slips. A piece of masking
tape applied to the wall before marking out the fixing holes will stop the drill from
wandering.
DO NOT strike glass components with hard or pointed items. DO NOT place very hot
or very cold items against or in close proximity to glass surfaces unless an adequately
thick insulation material is used to prevent such items coming in contact with the
glass.
The nominal thickness of the mirror glass used in this product is 3mm and is film
backed for safety. If the glass becomes chipped or broken replace immediately.
This product should be positioned well away from curtains and other fabrics. Never
cover the mirror. This product is heated, we recommend that it is turned off after use
and should never be left on for prolonged periods of time
This product could be dangerous and is only to be installed by a competent person.
CLEANING
It is recommended that the unit is cleaned with a soft, dry, non abrasive cloth when
turned off. Never use cleaning agents or abrasive materials on any type of surface
finish. Do not allow moisture to come into contact with the electrical components.
COMPLIANCE
This product complies with all relevant British and European safety standards.
WIRING
THIS PRODUCT IS MANUFACTURED TO CLASS I
CATEGORY AND MUST HAVE AN EARTH CONNECTION.
Colour Coding:
L - Live = Brown
N - Neutral = Blue
- Earth = Green & Yellow
! IF IN DOUBT CONSULT YOUR ELECTRICIAN !
LIGHTS
12V LED Lamp
To obtain a replacement lamp if faulty or broken contact customer services (see details
at foot of page)
Bathroom Zones Diagram
0.6m
0.75m
2
OUTSIDE
ZONES
Distances from a bath tub or shower tray
Strip wires to a suitable
length. DO NOT connect
to a plug & socket outlet.
0.6m
0.75m
2
ZONE
1
2
2
V1 / 11.15
