TDK-Lambda ELV60 Series Instruction Manual

BEFORE USING POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product.
Pay attention to all warnings and cautions before using the unit. Incorrect usage could lead to an electrical shock,
damage to the unit or a fire hazard
DANGER
Never use this product in locations where flammable gas or ignitable substances are present.
·
WARNING ON INSTALLATION
Follow the installation instructions in this manual. If installation has a defect, there is fear of an electric shock and a fire.
·
Qualified personnel (Electrical worker, etc.) who has experience needs to perform installation. There is fear of electric shock and fire.
·
Avoid mounting this product using fixing method other than screws (fixing with double-sided tape, or not fixing at all).
·
Do not cover with cloth or put paper on this product. Do not place flammable objects nearby.
·
They may cause damage, electric shock or fire.
WARNING ON USE
Do not touch the product while it is in operation or immediately after disconnecting power. There is a risk of burns on contact.
·
While this product is operating, keep your hands and face away from it as you may be injured by an unexpected accident.
·
Do not perform disassembly and reconstruction of this product, otherwise you may receive an electric shock and void your warranty.
·
Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound etc. It might lead to fire and
·
electric shock. In such cases, contact us. Do not attempt to repair by yourself, as it is dangerous for the user.
CAUTIONS ON INSTALLATION
The power supply unit is for LED lamp load. Never use it for other purpose than LED lamp load
·
Protection class IP66 shows initial protection class against dust and water. Performance may degrade depending usage environment.
·
In addition, for connection point of the input and output lines, take appropriate waterproofing. When the water enters inside the
power supply from the connection point of the wire, there is a risk of electric shock or fire or smoke
About connection of input and output line, check that it is performed appropriately as shown in this instruction manual. If wrong wire
·
connection is carried out, it may cause failure, electric shock, or fire. Particularly, be sure to avoid connecting input line and output
line in reverse
When wiring long input wire, use thick wires as possible, and lower input impedance as much as possible
·
If dropped or shock is applied to the unit, never use the unit because it might have caused damage.
·
Do not use in special environments such as direct sunshine, locations with exposure to water such as rain, strong magnetic field and
·
corrosive gas, etc.
For applications, which require very high reliability (Nuclear related equipment, traffic control equipment, etc.), it is necessary to
·
provide a fail-safe mechanism in the end equipment.
When handing this product, carry the main body. Avoid working with input and output line because it might cause damage.
·
CAUTIONS FOR USE
Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications,
·
otherwise it may cause failure, electric shock, or fire.
Never operate the product under over current or short-circuit conditions, or outside its specified Input Voltage Range.
·
Insulation failure, smoking, burning or other damage may occur.
Notice the abnormal voltage from the external to output. It may become the origin of the trouble (failure, electric shock, or fire) in
·
particular when power supply is applied overvoltage more than the rating voltage or the reverse voltage between the output.
OTHER CAUTIONS
Do not keep in places like the following.
·
Places with high temperature or high humidity, places in direct sunshine exposure, places where vibration and shock are applied,
places where corrosive gas is emitted.
When disposing this product, follow the disposal procedures of each local government.
·
The information in this document is subject to change without prior notice. Refer to the latest version of the data sheet, etc., for the
·
most up-to date specifications of the product.
No part of this document may be copied or reproduced in any form without prior written consent of TDK-Lambda.
·
