Summary of Contents for ROD-L M100DC
- Page 1 (217) 352-9330 | Click HERE Find the Rod-L M100DC at our website:...
- Page 2 OUTPUT VOLTAGE DURING TEST LINE POWER START CHASSIS GROUND SENSE RESET FOR MODELS: M100DC Phone: (650) 322-0711 • (800) 548-6305 (650) 326-1993 Fax: info@rodl.com • www.rodl.com Online: Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 3 (The power cord connects to the rear (The ground sense wire has a banana plug (If you are testing a DUT with other than panel of the ROD-L unit and to any which inserts into the “Chassis Ground a three prong grounded power cord, see Sense post on the front panel of the grounded three-prong wall socket.
- Page 4 V SET I SET FUSES AC CHASSIS GROUND SENSE LINE VOLTAGE BURN AC LINE REMOTE TEST 360 WATTS TEST RISE CHASSIS HV IN AC HIPOT GND SENSE HV OUT GT 1. Voltage Output Potentiometer (V-set): This potentiometer is a 10-turn vernier dial on which each full rotation corresponds to 10% of the maximum voltage output of the unit.To set the voltage, place the “run-set”...
- Page 5 There are a number of safety features built into ROD-L units that should never be removed or overridden. These are; 1) the chassis ground sense circuit, 2) The internal components of the front panel high voltage receptacle, 3) The recessed start button, 4) The alarm light and alarm tone, 5) The internal shut-down circuitry of the units, 6) The reset switch.
