- Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
-
Page 2: Quick Start Guide
OUTPUT VOLTAGE DURING TEST LINE POWER START CHASSIS REAL GROUND SENSE RESET FOR MODELS: M100AVS5 M100BVS5 M500AVS5 M500BVS5 Phone: (650) 322-0711 • (800) 548-6305 (650) 326-1993 Fax: info@rodl.com • www.rodl.com Online: Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 3: Self Test
(The power cord connects to the rear (The ground sense wire has a banana plug (If you are testing a DUT with other than panel of the ROD-L unit and to any which inserts into the “Chassis Ground a three prong grounded power cord, see Sense post on the front panel of the grounded three-prong wall socket. - Page 4 FUSES UNDER CURRENT TOTAL CURRENT REAL CURRENT TRIP POINT TRIP POINT TRIP POINT HV OUT/ INTERFACE GRND CHASSIS AC LINE REMOTE GND SENSE 360 WATTS 1. Large Variac Knob: The Variac scale is marked from 0 to 100, and can be interpreted as “percentage of full-scale capability of the unit” (e.g. 50 on the Variac would correspond to 2500 volts on a 5KV maximum unit, but only 1400 volts on a 2.8 kV maximum unit.
- Page 5 There are a number of safety features built into ROD-L units that should never be removed or overridden. These are; 1) the chassis ground sense circuit, 2) The internal components of the front panel high voltage receptacle, 3) The recessed start button, 4) The alarm light and alarm tone, 5) The internal shut-down circuitry of the units, 6) The reset switch.
