SMOKE ALARM USER MANUAL
Mod el Nu mber : FS A -3 0 0 0 0
Thank you for purchasing the FSA-30000 smoke alarm with Wireless Interconnect function.
Please take a few minute's to read this user's manual thoroughly.
PRODUCT SPECIFICATIONS
Power:
Operational Current:
Alarm Volume:
Smoke Sensitivity:
Inconnectibility:
Local alarm Sound Pattern:
Wireless alarm Soun Pattern: Alarms twice, pause 1 sec, red LED flashing, pattern
DESCRIPTION
This unit is a photoelectric type smoke alarm, and conforms to AS3786:2014.
M A T E L E C A U S T R A L I A . P 1 8 0 0 2 8 1 2 8 2 . F 1 3 0 0 2 8 1 2 8 2
I N F O @ M A T E L E C A U S T R A L I A . C O M . A U . W W W . M A T E L E C A U S T R A L I A . C O M . A U
Built in 3VDC (CR17450) Lithium Battery (non-replaceable)
<70mA
>85dB(A) at 3m
0.090-0.15dB/m
Up to 40 units
ISO 8201. Alarm sounds for 0.5 seconds, red LED flashing,
pattern repeated.
repeated.
TM
Advertisement
Table of Contents
Related Manuals for Matelec FSA-30000
Summary of Contents for Matelec FSA-30000
- Page 1 SMOKE ALARM USER MANUAL Mod el Nu mber : FS A -3 0 0 0 0 Thank you for purchasing the FSA-30000 smoke alarm with Wireless Interconnect function. Please take a few minute’s to read this user’s manual thoroughly. PRODUCT SPECIFICATIONS...
- Page 2 SUGGESTED SMOKE ALARM LOCATIONS 1. Smoke alarms must be installed in accordance with local and national regulations. Please check your state fire department requirements prior to installation. 2. As a minimum, smoke alarms should be located between sleeping areas and potential sources of fire such as a kitchen, heater or basement.
- Page 3 DEVELOP AN ESCAPE PLAN As part of your plan, all family members should know and/or practice: 1. The two quickest ways out of each room 2. How to exit from upstairs, for homes with a second story. A rope or chain may be required. 3.
- Page 4 DIAGRAM 3 6. The unit is now fully operational. Press the button for 2 seconds to test. The alarm will sound 3 short beeps, then a 1.5 second pause, then repeat, until the button is released. LED INDICATOR 1. Under normal operation, the red LED will flash once every 40 seconds. This is a very faint flash, and only visible through the vents on the side of the alarm.
- Page 5 WARRANTY • The FSA-30000 smoke alarm is warranted for a period of 5 years, to be free of defects in materials or workmanship, under normal use. In the event of a warranty issue, please contact MATelec Australia via email, at info@matelecaustralia.com.au.
Need help?
Do you have a question about the FSA-30000 and is the answer not in the manual?
Questions and answers
My FSA 30000/60000 keeps going off for no apparent reason. I have cleaned each of the units for dust and removed the battery from the main unit as well as the wireless module however they keep going off. They last about 20 seconds before stopping. Any advice on what to do? Thanks
The Matelec FSA-30000 uses a built-in, non-replaceable 3V lithium battery. If the unit turns off after 20 seconds despite cleaning, it may indicate a battery failure or internal fault. Since the battery cannot be replaced, the alarm may need to be replaced.
This answer is automatically generated
I had 4 Matelec FSA30000 smoke alarms installed 31.10.2022'. How do I know if the alarms are operational. I have heard smoke alarms usually either 'beep'' or a light shows every 40 seconds, to show they are operational. My alarms don't show any form of indication. How can I test them to see if they are functioning?
To test if your Matelec FSA-30000 smoke alarms are functioning properly, follow these steps:
1. Ensure each alarm is turned on by rotating the base.
2. Press and hold the control button on each alarm until it chirps to confirm operation.
3. To test the wireless connection, press and hold the control button for 4 seconds.
4. If the alarms are correctly connected, all connected alarms will chirp for 15 seconds.
This confirms that the alarms are functioning and communicating properly.
This answer is automatically generated
