db ProxLock
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the db ProxLock and is the answer not in the manual?

Questions and answers

Summary of Contents for Digitus Biometrics db ProxLock

  • Page 1 ProxLock Installation Manual...
  • Page 2: Table Of Contents

    Route the Cable between the lock and the door hinge – Step 3 ............7 Connect the cable to the Remote Node / db Sentry Controller – Step 4 ........... 8 Connect the db ProxLock to a 3 -party access control panel (ACM) – Step 5 ..........9...
  • Page 3: Determining Which Lock Pawl To Use

    1000-28 1000-U33 1000-26 1000-U34 1000-12 1000-U35 1000-11 1000-U36 1000-51 1000-U37 1000-52 1000-U38 1000-25 1000-U39 1000-53 1000-U40 1000-54 1000-U41 1000-10 1000-U42 1000-55 1000-U43 1000-56 1000-U44 Table 1 Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 3 of 10...
  • Page 4: Overview

    Overview If you are installing the lock into to a cabinet that already has a lock installed, remove the existing lock at this time. • Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 4 of 10...
  • Page 5: Securing The Door Lock - Step 1

    Pay particular attention to the rotation limiter. This is installed as shown depending on whether you have a right on • left hand opening door. Pawl Rotation Limiter Figure 1 Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 5 of 10...
  • Page 6: Mount The Tie-Down Pads To The Door And Cabinet - Step 2

    Ensure that the door surface is clean and free from any debris. (Using neat alcohol to clean the surface is highly • recommended. Allow drying time before proceeding.) Remove the protective cover from each tie-down pad and situate as shown in Figure 2. • Figure 2 Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 6 of 10...
  • Page 7: Route The Cable Between The Lock And The Door Hinge - Step 3

    Route the Cable between the lock and the door hinge – Step 3 Route the cable as show in Figure 3. Secure the cable to the tie-down pads using the supplied cable-ties. • Figure 3 Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 7 of 10...
  • Page 8: Connect The Cable To The Remote Node / Db Sentry Controller - Step 4

    Connect the cable to the Remote Node / db Sentry Controller – Step 4 Connect the RJ45 coupler to the RJ45 plug on the cable coming from the db ProxLock If the db ProxLock is being connected directly to a 3...
  • Page 9: Connect The Db Proxlock To A 3

    If the db ProxLock is being connect to a Digitus Node or Sentry, this step is not required. Orange/White – GND, Ground Orange – LOCK CTRL. Requires a 12V (24V if a 24V version of the db ProxLock was purchased) control line to unlock the handle Green/White –...
  • Page 10 Digitus Biometrics, Inc. 2 East Bryan Street, Suite 502 Savannah, GA 31401 USA Phone: 912-231-8175 Fax: 912.629.9478 www.digitus-biometrics.com support@digitus-biometrics.com Specifications subject to change without notice. Model: db ProxLock Version: May 2017 Digitus Biometrics, Inc. 2017 Page 10 of 10...
