  • Page 1 ISTRUZIONI MONTAGGIO TOP SCATOLATI INSTALLATION INSTRUCTIONS BOXY TOPS bagnarsi ad arte_bathing with art...
  • Page 2 installation manual WARNING! Check the integrity of the top prior to assembly. The top must be handled and stored on its side during the installation of it on the furniture.
  • Page 3 INSTALLATION DIAGRAM FOR GENERIC BOXY TOPS WITH TOP MOUNT SINK installation manual 1_ To fix the top at the desired height H. Trace the holes of the fixing 2_ Fix the bracket at the determined height, place the second bracket brackets making sure that the holes are at height C ( C = H - (X + 2,5) cm ).
  • Page 4 INSTALLATION DIAGRAM BOXY TOPS 12/14 MM THICK WITH INTEGRATED SINK installation manual 4 cm 1_ To fix the top at the desired height H. Trace the holes of the fixing 2_ Fix the bracket at the determined height, place the second bracket leveled brackets making sure that the holes are at height C ( C = H - 4 cm ).
  • Page 5 INSTALLATION DIAGRAM BOXY TOP 12/14 MM THICK WITH INTEGRATED SINK installation manual MINIMUM BORDER EXTREME RIGHT OR LEFT HAND SIDE 4 cm 1_ To fix the top at the desired height H. Trace the holes of the fixing 2_ Fix the bracket at the determined height, place the second bracket leveled brackets making sure that the holes are at height C ( C = H - 4 cm ).
  • Page 6 INSTALLATION DIAGRAM BOXY TOP 12/14 MM THICK WITH INTEGRATED SINK installation manual MINIMUM BORDERS RIGHT AND LEFT 4 cm 1_ To fix the top at the desired height H. Trace the holes of the fixing Fix the bracket at the determined height, place the second bracket brackets making sure that the holes are at height C ( C = H - 4 cm ).
