Summary of Contents for antoniolupi STECCA600
- Page 1 STECCA USAGE AND INSTALLATION MANUAL WARNING!!! We decline any and all responsibilities relative to eventual inaccuracies contained in this manual due to transcription errors. We invite all our clientele to control the items received prior to installation.
- Page 2 FIG.1 - FIG.2 soffitto Ceiling Floor pavimento g = minimum height from the ground is 60 cm v = lowest height from floor 60 cm m = minimum distance from side walls and from the ceiling is 10 cm *to power supply Pag 2...
- Page 3 TAB.1 Tab. 1 electric h x w centre to Weight Model Version power (cm) centre (cm) (kg) (watt) distance STECCA600 12x60 56,7 STECCA900 12x90 86,7 STECCA1200 12x120 116,7 Pag 3...
- Page 4 FIG.3 soffitto Ceiling Floor pavimento Fig. 3 Pag 4...
- Page 5 FIG.4 Fig. 4 Pag 5...
- Page 6 FIG.6- FIG.7 fase (marrone) neutro (blu) live (brown) neutral (blue) phase (braun) neutral (blau) phase (marron) neutre (bleu) ó neutro (azul) fase (marr Fig. 7 Pag 6...
- Page 7 Index 1 Information about the producer pag 7 2 Warnings and precautions pag 8 3 Instructions for assembly pag 11 4 Tools required for installation pag 11 5 Material found in the package pag 12 6 Pre-mounted radiator in the package pag 12 7 Predisposition for wall supports pag 13...
-
Page 8: Warning And Precautions
Please read carefully all warnings and precautions listed below. The instructions contained in the present manual can be downloaded from our website www.antoniolupi.it • The appliance operates at 230V AC. Make sure the line voltage corresponds. • The appliance belongs to class II and is electrically protected IPX4;... - Page 9 2. WARNING AND PRECAUTIONS • The appliance can be used by children less than 8 years old and by people with reduced physical capacity, sensory or mental, or lacking in experience or the necessary • knowledge, as long as under surveillance or after having received instructions regarding the safe use of the device and understanding of the dangers inherit to it.
- Page 10 2. WARNING AND PRECAUTIONS • Do not load or hang excessive weights, the flow rate of these structures is calculated to support max. 2 Kg. • The minimum height from the ground of these elements must not be less than 60 cm. CAUTION!! Some parts of the radiator may become very hot causing burns.
-
Page 11: Instructions For Assembly
3. INSTRUCTIONS FOR ASSEMBLY Read all instructions and measurements carefully for the correct assembly of the radiator listed in the present document in Tab.1, Fig.1, Fig.2 and Fig.3. WARNING!! • Connect to the line only after fixing mechanically the radiator to the wall. - Page 12 5. MATERIAL PROVIDED IN THE PACKAGE • 2 Complete anchors Ø8 - Cod. I • 2 Wall brackets - Code L • 2 Allen screws M5 - Code N 6. PRE-MOUNTED RADIATOR IN THE PACKAGE Before being packed, the radiator is supplied with some components in order to facilitate and speed up the phases of installation.
- Page 13 7. DISPOSITION OF WALL SUPPORTS • Withdraw from the accessory package the two “L” wall brackets, the plugs “I” and the screws “P” and “N”; • Prepare holes in the wall “O” for the plugs (Supplied “I” fixing bolts D.8 mm suitable for reinforced concrete walls); •...
- Page 14 7. CHRONOTHERMOSTAT MANUAL Stand-By Mode: In stand-by mode the device is switched off and projects a light blue ligh Manual start: the device is switched on by touching, for 5 seconds, the “TOUCH” switch on the side of the appliance. The status of on is shown by the turning on of a green light on the inside of the appliance.
-
Page 15: Conformity Declaration
9. NOTES FOR DISPOSING OF THE PRODUCT The presence of a crossed-out mobile container on the product indicates that within the European Union all electrical products and electronic devices are subject to special collection at the end of their life cycle. Do not dispose of these products in unsorted municipal waste.
