9
Volume Indication
Master Volume will be communicated with the
1 2 3 4 5
five LEDs in the row of Visual Indicators LEDs.
Volume of 1% will be indicated by the leftmost
LED as dimly lit, and 100% will be indicated with
all 5 Visual Indicator LEDs fully illuminated.
Visual Indicator LEDs
Visual indicator LEDs will illuminate purple
NIGHT MODE - enabled
when NIGHT MODE is active.
Mute will be indicated by the Status light.
Volume mute when Status LED is Blue and
slowly blinking.
Status LED
