6. Using the Illuminator
Turn on the illuminator moving the light intensity
knob (Fig. 7).
①
Set the desired light intensity according the
specimen under examination.
Bend the self-supporting arms to aim the light
②
beam (Fig. 8)
.
Each arm can be oriented in a separate way, in
①
order to achieve a proper illumination (Fig. 9)
Fig.7
②
Fig.8 Fig.9
