Summary of Contents for Estella 348DSC67
- Page 1 01/2021 USER MANUAL DOUGH SHEETERS COUNTERTOP MODELS 348DSC67 348DSC78 17"W x 67"L Belt 19¾"W x 78"L Belt FLOOR MODELS 348DSF78 348DSF94 19¾"W x 78¾"L Belt 24¾"W x 95"L Belt...
-
Page 2: Table Of Contents
INDEX Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Setup . - Page 3 SAFETY When using electrical appliances, basic safety precautions should always be followed, including the following: 1 . Keep the working around surrounding the machine clean and organized . 2 . Consider environmental conditions surrounding the machine . Do not use the machine in humid, wet or poorly lit environments .
-
Page 4: Setup
SETUP NOTE: The manufacturer is not responsible for any damages caused by improper installation. NOTE: The machine should be run with a batch of test dough that will not be used for consumption. This is necessary to remove any lubricants that are on the rollers/belts from the new machine. COUNTERTOP MODELS 1 . -
Page 5: Operation
OPERATION WARNING: MOVING PARTS CAN CRUSH & CUT Keep hands, feet and all objects away from the rollers prior to turning on the machine! 1 . Ensure the machine is properly installed and the working space is free of any potential hazards . - Page 6 IMPROPER USE OF THIS MACHINE Estella Dough Sheeters are designed to be used by qualified and trained pastry chefs and bakers . TT-D18A Operating Steps: 1. Turn on the power switch. (Before start the switch, you need to check whether the emergency stop switch is turned on and safety nets are...
-
Page 7: Circuit Diagram
CIRCUIT DIAGRAM Safety Guard Left/Right Direction Ground Wire Power Input Microswitch Microswitch Safety Guard KM1 AC Contactor Motor On/Off Switch Microswitch Left/Right Direction Emergency Stop KM2 AC Contactor Power Input Microswitch Button Safety Guard Left/Right Direction Ground Wire Power Input Microswitch Microswitch Safety Guard... -
Page 8: Troubleshooting
TROUBLESHOOTING Issue Cause Solution The machine is not plugged in or Check the general switch, the plug, and connected to a source of power the feeding cable The voltage input is incorrect Use the proper voltage The machine won’t start There is another issue with the Stop using the machine immediately and machine... -
Page 9: Limited Warranty
Estella shall not be liable, under any legal theory, for loss of use, revenue or profit, or for substitute use or performance, or for incidental, indirect, or special or consequential damages or for any other loss of cost of similar type .
