System tour

Your computer consists of the following:

Front panel

Icon
Description
Power button
Microphone jack
Speaker or
headphone jack
USB port

Rear panel

Icon
Description
PS/2 keyboard connector
VGA port
Printer connector
Microphone-in jack
Line-in jack
HDMI
HDMI port (selected
models only)
Icon
Description
Floppy drive
(selected models only)
Optical drive
(selected models only)
Media card reader
(selected models only)
IEEE 1394 port
(selected models only)
Icon
Description
PS/2 mouse connector
Serial port
(selected models only)
USB port
RJ-45 Ethernet connector
Line-out / Speaker-out
jack
1
